產品用途：丁腈電力電纜具有耐寒、柔軟、耐磨、防油等特性，適用于交流額定電壓0.6/1KV及以下具有耐寒、防油等特殊要求的移動電器用連接電纜，目前本產品已廣泛應用于冶金、電力、船舶、汽車制造等行業。Product Usage: Nitrile power cables have characteristics such as cold resistance, softness, wear resistance, and oil resistance. They are suitable for connecting mobile electrical cables with special requirements such as cold resistance and oil resistance for AC rated voltages of 0.6/1KV and below. Currently, this product has been widely used in industries such as metallurgy, power, shipbuilding, and automotive manufacturing.

使用特性

Properties

1.交流額定電壓：U0/U 0.6/1KV

工作溫度： 105℃

環境溫度：固定敷設-40℃

2.電纜安裝敷設溫度應不低于-25℃。

3.電纜允許彎曲半徑：電纜外徑的12倍

1. AC rated voltage: U0/U 0.6/1KV

Working temperature: 105 ℃

Environmental temperature: Fixed laying -40 ℃

2.The installation and laying temperature of cables should not be lower than -25 ℃.

3. Cable allowable bending radius: 12 times the outer diameter of the cable

型號 model	產品M稱 product name
YVFR	丁腈J緣和護套電力軟電纜Nitrile insulated and sheathed power flexible cables
YVFRP	丁腈J緣和護套銅編織屏蔽電力軟電纜Nitrile insulated and sheathed copper braided shielded power flexible cables
備注：阻燃電纜型號前加ZR，導體線芯中銅絲可以采用鍍錫。Note: Add ZR before the flame-retardant cable model, and the copper wire in the conductor core can be tinned.

代號M稱和含義 表2   Table 2 of Code Names and Meanings

代號 code	代號含義  Meaning of code
YVF	丁腈電纜系列  Nitrile cable series
R	多股絞合導體 stranded conductor
P	銅編織屏蔽Copper braided shielding

主要技術指標 Specification
1.成品電纜導體（R類）直流電阻（符合GB3956規定）參照附錄A表2。1. The finished cable conductor (Class R) DC resistance (in accordance with GB3956 regulations) shall refer to Appendix A Table 2.
2.20℃時J緣電阻不小于50MΩ/KM。
3.成品電纜經受交流50HZ3.5KV/5min電壓試驗不擊穿。 基本電纜規格及結構參數  3. The finished cable shall withstand an AC voltage test of 50Hz, 3.5KV, and 5min without breakdown. Basic cable specifications and structural parameters

線芯*標稱截面（mm2） Core * nominal cross-section	導體結構 （根數*直徑） Conductor structure (Number of pieces * diameter) （B/R） mm	電纜外徑Cable outer diameter		參考重量（kg/km）Reference weight
		YVFR	YVFRP	YVFR	YVFRP
1*2.5	51*0.25	4.0	-	72	-
1*4	82*0.25	6.0	-	95	-
1*6	123*0.25	7.0	-	130	-
1*10	204*0.25	9.5	-	190	-
1*16	323*0.25	11.0	-	255	-
1*25	513*0.25	12.0	-	365	-
1*35	722*0.25	13.5	-	475	-
1*50	1026*0.25	15.0	-	670	-
1*70	1406*0.25	17.0	-	830	-
1*95	486*0.50	19.0	-	1200	-
1*120	608*0.50	21.0	-	1360	-
1*150	760*0.50	23.0	-	1654	-
1*185	945*0.50	26.0	-	2050	-
2*2.5	51*0.25	10.5	11.5	159	205
2*4	82*0.25	12.5	13.5	230	290
2*6	123*0.25	14.0	15.2	276	336
2*10	204*0.25	18.0	19.2	413	475
2*16	323*0.25	22.0	23.5	567	670
2*25	513*0.25	24.5	25.5	833	933
2*35	722*0.25	29.0	30.2	1088	1288
2*50	1026*0.25	33.0	35.0	1297	1590
2*70	1406*0.25	38.0	39.0	1675	1900
2*95	486*0.50	41.0	43.0	2205	2500
2*120	608*0.50	48.0	50.0	2660	3000
2*150	760*0.50	52.0	54.0	3350	3750
2*185	945*0.50	57.0	59.0	4400	4820
3*2.5	51*0.25	12.0	13.0	210	270
3*4	82*0.25	13.0	14.0	295	365
3*6	123*0.25	14.8	15.8	375	455
3*10	204*0.25	19.0	20.0	559	639
3*16	323*0.25	22.0	23.0	770	870
3*25	513*0.25	26.0	27.0	1239	1349
3*35	722*0.25	33.0	34.1	1520	1640
3*50	1026*0.25	36.5	38.5	1970	2100
3*70	1406*0.25	40.5	42.5	2580	2790
3*95	486*0.50	48.5	50.5	3280	3500
3*120	608*0.50	53.0	55.0	4060	4380
3*150	760*0.50	58.0	60.0	5197	5597
3*185	945*0.50	63.0	65.0	6279	6700
3*4+1*2.5	82*0.25	14.5	15.6	300	370
3*6+1*4	123*0.25	16.0	17.2	400	490
3*10+1*6	204*0.25	21.0	23.0	590	690
3*16+1*10	323*0.25	25.0	26.0	850	950
3*25+1*16	513*0.25	30.5	32.5	1255	1410
3*35+1*16	722*0.25	33.5	35.6	1585	1790
3*50+1*25	1026*0.25	40.2	42.2	2066	2280
3*70+1*35	1406*0.25	47.2	49.5	2778	3080
3*95+1*50	486*0.50	50.0	52.2	2836	3126
3*120+1*70	608*0.50	53.0	55.5	4857	5207
3*150+1*70	760*0.50	57.0	59.5	5700	6090
3*185+1*95	945*0.50	66.0	69.0	7114	7514
4*4	82*0.25	14.0	15.0	325	400
4*6	123*0.25	17.5	18.5	421	500
4*10	204*0.25	22.0	23.0	635	720
4*16	323*0.25	24.0	25.0	898	1010
4*25	513*0.25	31.0	32.0	1342	1490
4*35	722*0.25	34.0	35.0	1765	1900
