- 產(chǎn)品名稱：WDZ-JKYDPYDRP computer cable
- 瀏覽：
- 添加時間：2024-04-02 10:12:30
- 推薦度：
Full name: WDZ-JKYDPYDRP Copper core halogen-free low smoke flame-retardant polyolefin insulated and sheathed copper wire or tin plated copper wire woven split screen total screen computer control flexible cable
Product model: WDZ-JKYDPYDRP
Product abbreviation: Tin plated copper wire braided split screen main screen computer control soft cable
Conductor material: oxygen free copper wire
Insulation material: halogen-free low smoke flame-retardant polyolefin insulation
Shielding material: Copper wire or tin plated copper wire woven split screen total screen
Sheath material: halogen-free low smoke flame-retardant polyolefin sheath
Structure: Twisted type
Core wire color: Distinguish colors within 5 cores, black wires above 5 cores with white numerical numbers
Flame retardancy: in accordance with IEC60332
Working voltage: 450/750V
Factory test voltage: 2000V-3000V
Very small bending radius: cable outer diameter * 8 times
The long-term working temperature should not exceed+105 ℃
The long-term working temperature should not be lower than -0 ℃
Flexibility, moisture resistance, cold resistance, oil resistance, and UV resistance
Can withstand moderate mechanical stress
Has strong resistance to electromagnetic interference
