- 產品名稱：High voltage drum round cable高壓卷筒電纜YJGCFRP
- 瀏覽：
- 添加時間：2024-06-03 15:37:15
- 推薦度：
產品特點及用途
Product features and uses
本產品為高壓卷筒圓電纜適用于交流額定電壓6/10KV料場、碼頭、礦山、港口的堆取料機及港機上變壓器連接用高壓圓電纜，導體采用鍍錫軟芯結構，導體絕緣采用進口硅橡膠絕緣材料，電纜具有耐高溫、耐寒、耐油、耐腐蝕、防油、耐磨等特性。產品廣泛用于冶金、礦山、電力、石油化、船舶工業、港口及移動設備制造等行業。
This product is a high-voltage drum round cable suitable for connecting the stacker reclaimer and transformer on the AC rated voltage of 6/10KV material yards, docks, mines, and ports. The conductor adopts a tinned soft core structure, and the insulation of the conductor uses imported silicone rubber insulation material. The cable has characteristics such as high temperature resistance, cold resistance, oil resistance, corrosion resistance, oil resistance, and wear resistance. The product is widely used in industries such as metallurgy, mining, electricity, petrochemicals, shipbuilding, ports, and mobile equipment manufacturing.
使用特性：
Usage characteristics:
1、額定電壓：UO/U為0.6/1KV；
1. Rated voltage: UO/U is 0.6/1KV;
2、電纜允許工作溫度范圍：硅橡膠絕緣-60℃— +180℃；氟塑料絕緣-60℃－ +200℃；
2. The allowable working temperature range of cables: silicone rubber insulation -60 ℃ -+180 ℃; Fluoroplastic insulation -60 ℃ -+200 ℃;
3、電纜短路時（最長持續間不超過5S）電纜導體的最高溫度不超過250℃；
3. When the cable is short circuited (with a maximum duration of 5 seconds), the maximum temperature of the cable conductor shall not exceed 250 ℃;
4、電纜敷設溫度應不低于- 20℃；
4. The cable laying temperature should not be lower than -20 ℃;
5、電纜最小彎曲半徑為電纜小邊長度的10倍；
5. The minimum bending radius of the cable is 10 times the length of the smaller side of the cable;
電纜型號及名稱
Cable model and name
型號 名稱
Model name
YGCB 銅芯硅橡膠絕緣及護套扁電纜
YGCB copper core silicone rubber insulated and sheathed flat cable
YGCPB 銅芯硅橡膠絕緣及護套編織屏蔽扁電纜
YGCPB copper core silicone rubber insulated and sheathed braided shielded flat cable
YGGB 銅芯硅橡膠絕緣及護套扁平電纜
YGGB copper core silicone rubber insulated and sheathed flat cable
YF46GRB 銅芯氟塑料絕緣硅橡膠護套扁平軟電纜
YF46GRB copper core fluoroplastic insulated silicone rubber sheathed flat flexible cable
YFGRPB 銅芯氟塑料絕緣硅橡膠護套編織屏蔽軟扁電纜
YFGRPB copper core fluoroplastic insulated silicone rubber sheathed braided shielded soft flat cable
YFGB 銅芯氟塑料絕緣硅橡膠護套扁平電纜
YFGB copper core fluoroplastic insulated silicone rubber sheathed flat cable
HGGB 銅芯硅橡膠絕緣硅橡膠護套扁平電纜
HGGB copper core silicone rubber insulated silicone rubber sheathed flat cable
YGGB-J 銅芯硅橡膠絕緣及護套加鋼絲加強芯硅橡膠扁電纜
YGGB-J Copper Core Silicone Rubber Insulation and Sheath with Steel Wire Reinforced Core Silicone Rubber Flat Cable
KGGB 銅芯硅橡膠絕緣及護套扁平電纜
KGGB copper core silicone rubber insulated and sheathed flat cable
KGGPB 銅芯硅橡膠絕緣及護套編織屏蔽扁平電纜
KGGPB copper core silicone rubber insulated and sheathed braided shielded flat cable
KFGB 銅芯氟塑料絕緣硅橡膠護套扁平電纜
KFGB copper core fluoroplastic insulated silicone rubber sheathed flat cable
KFGPB 銅芯氟塑料絕緣硅橡膠護套編織屏蔽扁平電纜
KFGPB copper core fluoroplastic insulated silicone rubber sheathed braided shielded flat cable
KGVPB 銅芯硅橡膠絕緣丁硅聚氯乙烯護套編織屏蔽扁平電纜
KGVPB copper core silicone rubber insulated butadiene silicone polyvinyl chloride sheathed braided shielded flat cable
KGGRPB 銅芯硅橡膠絕緣及護套編織屏蔽軟扁平電纜
KGGRPB copper core silicone rubber insulated and sheathed braided shielded soft flat cable
KF46GPB 銅芯氟塑料絕緣硅橡膠護套編織屏蔽扁平電纜
KF46GPB copper core fluoroplastic insulated silicone rubber sheathed braided shielded flat cable
KFGRPB 銅芯氟塑料絕緣硅橡膠護套編織屏蔽扁平電纜
KFGRPB copper core fluoroplastic insulated silicone rubber sheathed braided shielded flat cable
KGGRB 銅芯硅橡膠絕緣及護套扁平電纜
KGGRB copper core silicone rubber insulated and sheathed flat cable
備注：阻燃電纜型號前加ZR，導體線芯中銅絲可以采用鍍錫。
Note: Add ZR before the flame-retardant cable model, and the copper wire in the conductor core can be tinned.
