- 產品名稱：Silicone rubber flat cable YGCPB
- 瀏覽：
- 添加時間：2024-06-07 10:30:36
- 推薦度：
一，YGCPB硅橡膠絕緣扁電纜,銅芯硅橡膠絕緣及護套編織屏蔽扁電纜,采用硅橡膠作絕緣或護套材料，由于硅橡膠本身具有耐高溫，耐寒,柔軟,耐磨,防腐等特性，因此該電纜高溫環境下電氣性能穩定，抗老化性能好，使用壽命長，適合于交流1KV及以下具有抗拉，耐熱，防腐等特殊要求的行車，臺車，傳輸機械等移動設備和電器用動力傳輸線及控制，照明，通訊線路，硅橡膠扁電纜已廣泛應用于冶金，電力，化工，船舶，港口等行業。
1、 YGCPB silicone rubber insulated flat cable, copper core silicone rubber insulated and sheathed braided shielded flat cable, uses silicone rubber as the insulation or sheath material. Because silicone rubber itself has the characteristics of high temperature resistance, cold resistance, softness, abrasion resistance, corrosion resistance, etc., the cable has stable electrical performance, good aging resistance, and long service life under high temperature environment. It is suitable for driving vehicles, trolleys, transmission machinery and other mobile equipment with special requirements for tension, heat resistance, corrosion resistance, and power transmission lines and control, lighting, communication lines for electrical appliances. Silicon rubber flat cables have been widely used in metallurgy, power, chemical, shipping, port and other industries.
二，使用特性：
2、 Usage characteristics:
1,額定電壓：UO/U為0.6/1KV；
1. Rated voltage: UO/U is 0.6/1KV;
2,電纜允許工作溫度范圍：硅橡膠絕緣-60℃— 180℃；氟塑料絕緣-60℃－ 200℃；
2. The allowable working temperature range of the cable: silicone rubber insulation -60 ℃ -180 ℃; Fluoroplastic insulation -60 ℃ -200 ℃;
3,電纜短路時（長持續間不超過5S）電纜導體的高溫度不超過250℃；
3. When the cable is short circuited (lasting for no more than 5 seconds), the high temperature of the cable conductor shall not exceed 250 ℃;
4,電纜敷設溫度應不低于-20℃；
4. The cable laying temperature should not be lower than -20 ℃;
5,電纜小彎曲半徑為電纜小邊長度的10倍
5. The small bending radius of the cable is 10 times the length of the small side of the cable
三，其他******電纜型號，名稱
3、 Other similar cable models and names
YGCB 銅芯硅橡膠絕緣及護套扁電纜
YGCB copper core silicone rubber insulated and sheathed flat cable
YGCPB 銅芯硅橡膠絕緣及護套編織屏蔽扁電纜
YGCPB copper core silicone rubber insulated and sheathed braided shielded flat cable
YGGB 銅芯硅橡膠絕緣及護套扁平電纜
YGGB copper core silicone rubber insulated and sheathed flat cable
YF46GRB 銅芯氟塑料絕緣硅橡膠護套扁平軟電纜
YF46GRB copper core fluoroplastic insulated silicone rubber sheathed flat flexible cable
YFGRPB 銅芯氟塑料絕緣硅橡膠護套編織屏蔽軟扁電纜
YFGRPB copper core fluoroplastic insulated silicone rubber sheathed braided shielded soft flat cable
YFGB 銅芯氟塑料絕緣硅橡膠護套扁平電纜
YFGB copper core fluoroplastic insulated silicone rubber sheathed flat cable
HGGB 銅芯硅橡膠絕緣硅橡膠護套扁平電纜
HGGB copper core silicone rubber insulated silicone rubber sheathed flat cable
YGGB-J 銅芯硅橡膠絕緣及護套加鋼絲加強芯硅橡膠扁電纜
YGGB-J Copper Core Silicone Rubber Insulation and Sheath with Steel Wire Reinforced Core Silicone Rubber Flat Cable
KGGB 銅芯硅橡膠絕緣及護套扁平電纜
KGGB copper core silicone rubber insulated and sheathed flat cable
KGGPB 銅芯硅橡膠絕緣及護套編織屏蔽扁平電纜
KGGPB copper core silicone rubber insulated and sheathed braided shielded flat cable
KFGB 銅芯氟塑料絕緣硅橡膠護套扁平電纜
KFGB copper core fluoroplastic insulated silicone rubber sheathed flat cable
