- 產品名稱：High temperature compensation wire KX-HA-FGR
- 瀏覽：
- 添加時間：2024-07-08 10:03:44
- 推薦度：
一：產品特點及用途
1： Product features and uses
熱電偶補償導線 KX-HA-FGR KX-HA-FGRP一般用聚氯乙烯絕緣和護套補償導線或電纜具有優良的防潮、耐磨及阻燃特性；耐高溫氟 安徽中盛電氣集團有限公司
Thermocouple compensation wire KX-HA-FGR KX-HA-FGRP is generally made of PVC insulated and sheathed compensation wire or cable, which has excellent moisture-proof, wear-resistant, and flame retardant properties; High temperature resistant fluorine
補償導線或電纜采用連續擠出工藝，更有耐高溫、耐寒、耐酸堿油水、不延燃、抗老化等優越性，產品質量高于國標GB/T4989-94(等
The compensation conductor or cable adopts continuous extrusion process, which has more advantages of high temperature resistance, cold resistance, acid, alkali, oil and water resistance, non flame retardance, aging resistance, etc. The product quality is higher than the national standard GB/T4989-94 (etc
3)的規定。
3) The regulations.
熱電偶補償導線 KX-HA-FGR KX-HA-FGRP采用低電容、低電感材料結構，具有防爆安全性能，適用于有爆炸危險的環境下作防爆熱
The thermocouple compensation wire KX-HA-FGR KX-HA-FGRP adopts a low capacitance and low inductance material structure, which has explosion-proof safety performance and is suitable for explosion-proof heating in environments with explosion hazards
測溫儀表連接，形成本安熱電偶測溫系統。安徽中盛電氣集團有限公司
Connect the temperature measuring instrument to form an intrinsic safety thermocouple temperature measurement system.
二：熱電偶補償導線 KX-HA-FGR KX-HA-FGRP產品執行標準
2： Thermocouple compensation wire KX-HA-FGR KX-HA-FGRP product execution standard
GB/T4989-94(等效采用IEC584-3標準)
GB/T4989-94 (equivalent to IEC584-3 standard)
三：熱電偶補償導線 KX-HA-FGR KX-HA-FGRP使用特性安徽中盛電氣集團有限公司
3： Usage characteristics of thermocouple compensation wire KX-HA-FGR KX-HA-FGRP
1． 導體***高工作溫度：耐熱級：聚全氟乙丙烯(F46)200℃
1. Conductor * * * High working temperature: Heat resistance level: Polyfluoroethylene propylene (F46) 200 ℃
可溶性聚四氟乙烯260℃
Soluble polytetrafluoroethylene 260 ℃
硅橡膠180℃
Silicone rubber 180 ℃
普通級：聚氯乙烯70℃和105℃，交聯聚乙烯90℃
Ordinary grade: PVC at 70 ℃ and 105 ℃, cross-linked polyethylene at 90 ℃
低煙無鹵阻燃聚烯烴70℃，交聯型90℃和125℃
Low smoke halogen-free flame retardant polyolefin at 70 ℃, cross-linked at 90 ℃ and 125 ℃
2． 低環境溫度： 聚氯乙烯護套：固定敷設-40℃，非固定敷設-15℃
2. Low ambient temperature: PVC sheath: fixed laying -40 ℃, non fixed laying -15 ℃
氟塑料絕緣和護套：固定敷設-60℃，非固定敷設-20℃
Fluoroplastic insulation and sheath: fixed laying -60 ℃, non fixed laying -20 ℃
3． 電纜允許彎曲半徑： 非鎧裝電纜***小為外徑的6倍 安徽中盛電氣集團有限公司
3. Cable allowable bending radius: For non armored cables, the minimum allowable bending radius is 6 times the outer diameter
銅帶屏蔽或鋼帶鎧裝點纜***小為電纜外徑的12倍
Copper tape shielded or steel tape armored point cable * * * is less than 12 times the outer diameter of the cable
氟塑料絕緣和護套***小為電纜外徑的10倍
Fluoroplastic insulation and sheath * * * are less than 10 times the outer diameter of the cable
四：基本型號及名稱
4： Basic model and name
KX-HA-FF 氟塑料絕緣和護套精密級K分度號熱電偶補償導線 安徽中盛電氣集團有限公司
KX-HA-FF fluoroplastic insulation and sheath, precision grade K-grade thermocouple compensation wire
KX-HA-FFR 氟塑料絕緣和護套精密級K分度號熱電偶補償軟導線
KX-HA-FFR fluoroplastic insulation and sheath, precision grade K-grade thermocouple compensation flexible wire
KX-HA-FFP 氟塑料絕緣和護套銅絲編織屏蔽精密級K分度號熱電偶補償導線
KX-HA-FFP Fluoroplastic Insulation and Sheath Copper Wire Braided Shield Precision Grade K Division Thermocouple Compensation Wire
KX-HA-FFRP 氟塑料絕緣和護套銅絲編織屏蔽精密級K分度號熱電偶補償軟導線
KX-HA-FFRP fluoroplastic insulation and sheath, copper wire braided shielding, precision grade K-grade thermocouple compensation flexible wire
KX-HA-FG 氟塑料絕緣硅橡膠護套精密級K分度號熱電偶補償導線
KX-HA-FG fluoroplastic insulated silicone rubber sheathed precision grade K-grade thermocouple compensation wire
KX-HA-FGR 氟塑料絕緣硅橡膠護套精密級K分度號熱電偶補償軟導線
KX-HA-FGR fluoroplastic insulated silicone rubber sheathed precision grade K-grade thermocouple compensation flexible wire
KX-HA-FGP 氟塑料絕緣硅橡膠護套銅絲編織屏蔽精密級K分度號熱電偶補償導線 安徽中盛電氣集團有限公司
KX-HA-FGP Fluoroplastic Insulated Silicone Rubber Sheath Copper Wire Braided Shield Precision Grade K Division Thermocouple Compensation Wire
KX-HA-FGRP 氟塑料絕緣硅橡膠護套銅絲編織屏蔽精密級K分度號熱電偶補償軟導線
KX-HA-FGRP fluoroplastic insulated silicone rubber sheathed copper wire braided shielding precision grade K-division thermocouple compensation flexible wire
KX-HA-FV 氟塑料絕緣聚氯乙烯護套精密級K分度號熱電偶補償導線
KX-HA-FV fluoroplastic insulated polyvinyl chloride sheathed precision grade K-grade thermocouple compensation wire
KX-HA-FVR 氟塑料絕緣聚氯乙烯護套精密級K分度號熱電偶補償軟導線
KX-HA-FVR fluoroplastic insulated polyvinyl chloride sheathed precision grade K-grade thermocouple compensation flexible wire
KX-HA-FVP 氟塑料絕緣聚氯乙烯護套銅絲編織屏蔽精密級K分度號熱電偶補償導線
KX-HA-FVP fluoroplastic insulated PVC sheathed copper wire braided shielding precision grade K-division thermocouple compensation wire
KX-HA-FVRP 氟塑料絕緣聚氯乙烯護套銅絲編織屏蔽精密級K分度號熱電偶補償軟導線 安徽中盛電氣集團有限公司
KX-HA-FVRP fluoroplastic insulated polyvinyl chloride sheathed copper wire braided shielding precision grade K-division thermocouple compensation flexible wire
KX-GA-YJV 交聯聚乙烯絕緣聚氯乙烯護套精密級K分度號熱電偶補償導線
KX-GA-YJV cross-linked polyethylene insulated polyvinyl chloride sheathed precision grade K-grade thermocouple compensation wire
KX-GA-YJVR 交聯聚乙烯絕緣聚氯乙烯護套精密級K分度號熱電偶補償軟導線
KX-GA-YJVR cross-linked polyethylene insulated polyvinyl chloride sheathed precision grade K-grade thermocouple compensation flexible wire
KX-GA-YJVP 交聯聚乙烯絕緣聚氯乙烯護套銅絲編織屏蔽精密級K分度號熱電偶補償導線
KX-GA-YJVP cross-linked polyethylene insulated polyvinyl chloride sheathed copper wire braided shielding precision grade K-division thermocouple compensation wire
KX-GA-YJVRP 低煙無鹵絕緣和護套銅絲編織屏蔽精密級K分度號熱電偶補償軟導線
KX-GA-YJVRP Low Smoke Halogen Free Insulation and Sheath Copper Wire Braided Shield Precision Grade K Division Thermocouple Compensation Flexible Wire
KX-GA-YDYD 低煙無鹵絕緣和護套精密級K分度號熱電偶補償導線 安徽中盛電氣集團有限公司
KX-GA-YDYD Low Smoke Halogen Free Insulation and Sheath Precision K-Division Thermocouple Compensation Wire
KX-GA- YDYD R 低煙無鹵絕緣和護套精密級K分度號熱電偶補償軟導線
KX-GA-YDYD R Low Smoke Halogen Free Insulation and Sheath Precision Grade K Division Thermocouple Compensation Flexible Wire
KX-GA- YDYD P 低煙無鹵絕緣和護套銅絲編織屏蔽精密級K分度號熱電偶補償導線
KX-GA-YDYD P Low Smoke Halogen Free Insulation and Sheath Copper Wire Braided Shield Precision Grade K Division Thermocouple Compensation Wire
KX-GA- YDYD RP 低煙無鹵絕緣和護套銅絲編織屏蔽精密級K分度號熱電偶補償軟導線
KX-GA-YDYD RP Low Smoke Halogen Free Insulation and Sheath Copper Wire Braided Shield Precision Grade K Division Thermocouple Compensation Flexible Wire
2：本安型熱電偶用補償導線
2: Compensation wires for intrinsically safe thermocouples
IA-KX-GA-YVP 聚乙烯絕緣聚氯乙烯護套銅絲編織屏蔽精密級K分度號本安熱電偶補償導線
IA-KX-GA-YVP Polyethylene Insulated PVC Sheath Copper Wire Braided Shield Precision Grade K Division Number Intrinsic Safety Thermocouple Compensation Wire
IA-KX-GA-YVRP 聚乙烯絕緣聚氯乙烯護套銅絲編織屏蔽精密級K分度號本安熱電偶補償軟導線
IA-KX-GA-YVRP Polyethylene Insulated PVC Sheath Copper Wire Braided Shield Precision Grade K Division Number Intrinsic Safety Thermocouple Compensation Flexible Wire
IA-KX-HA-FFP 氟塑料絕緣和護套銅絲編織屏蔽精密級K分度號本安熱電偶補償導線 安徽中盛電氣集團有限公司
IA-KX-HA-FFP Fluoroplastic Insulation and Sheath Copper Wire Braided Shield Precision Grade K Division Number Intrinsic Safety Thermocouple Compensation Wire
IA-KX-HA-FFRP 氟塑料絕緣和護套銅絲編織屏蔽精密級K分度號本安熱電偶補償軟導線
IA-KX-HA-FFRP Fluoroplastic Insulation and Sheath Copper Wire Braided Shield Precision Grade K Division Number Intrinsic Safety Thermocouple Compensation Flexible Wire
IA-KX-HA-FGP 氟塑料絕緣硅橡膠護套銅絲編織屏蔽精密級K分度號本安熱電偶補償導線
IA-KX-HA-FGP Fluoroplastic Insulated Silicone Rubber Sheath Copper Wire Braided Shield Precision Grade K Division Number Intrinsic Safety Thermocouple Compensation Wire
IA-KX-HA-FGRP 氟塑料絕緣硅橡膠護套銅絲編織屏蔽精密級K分度號本安熱電偶補償軟導線
IA-KX-HA-FGRP Fluoroplastic Insulated Silicone Rubber Sheath Copper Wire Braided Shield Precision Class K Division Number Intrinsic Safety Thermocouple Compensation Flexible Wire
3：補償電纜
3: Compensation cable
KX-GA-VVP 聚氯乙烯絕緣和護套銅絲編織總屏蔽精密級K分度號
KX-GA-VVP PVC insulation and sheath copper wire braided total shielding precision grade K graduation number
熱電偶用補償電纜
Compensation cables for thermocouples
KX-GA-VVRP 聚氯乙烯絕緣和護套銅絲編織總屏蔽精密級K分度號
KX-GA-VVRP PVC insulation and sheath copper wire braided total shielding precision grade K graduation number
熱電偶用補償軟電纜
Compensating flexible cables for thermocouples
KX-GA-VPVP 聚氯乙烯絕緣和護套銅絲編織分屏加總屏蔽精密級K
KX-GA-VPVP PVC insulation and sheath, copper wire braided split screen, total shielding, precision grade K
分度號熱電偶用補償電纜
Compensation cable for graduated thermocouple
KX-GA-VPVRP 聚氯乙烯絕緣和護套銅絲編織分屏加總屏蔽精密級K
KX-GA-VPVRP PVC insulation and sheath, copper wire braided split screen, total shielding, precision grade K
分度號熱電偶用補償軟電纜 安徽中盛電氣集團有限公司
Compensating flexible cable for graduated thermocouples
KX-GA-YJVP 交聯聚乙烯絕緣聚氯乙烯護套銅絲編織總屏蔽精密級
KX-GA-YJVP cross-linked polyethylene insulation polyvinyl chloride sheath copper wire braided total shielding precision grade
K分度號熱電偶用補償電纜
Compensation cable for K-grade thermocouple
KX-GA-YJVRP 交聯聚乙烯絕緣聚氯乙烯護套銅絲編織總屏蔽精密級
KX-GA-YJVRP cross-linked polyethylene insulation polyvinyl chloride sheath copper wire braided total shielding precision grade
K分度號熱電偶用補償軟電纜
Compensation flexible cable for K-grade thermocouple
KX-GA-YJPVP 交聯聚乙烯絕緣聚氯乙烯護套銅絲編織分屏加總屏蔽
KX-GA-YJPVP cross-linked polyethylene insulated polyvinyl chloride sheathed copper wire braided split screen total shielding
精密級K分度號熱電偶用補償電纜 安徽中盛電氣集團有限公司
Compensation cables for precision grade K-grade thermocouples
KX-GAYJPVRP 交聯聚乙烯絕緣聚氯乙烯護套銅絲編織分屏加總屏蔽
KX-GAYJPVRP cross-linked polyethylene insulation, polyvinyl chloride sheath, copper wire braided split screen, total shielding
精密級K分度號熱電偶用補償軟電纜
Compensation flexible cable for precision grade K-grade thermocouples
KX-HA-FFP 氟塑料烯絕緣和護套銅絲編織總屏蔽精密級K分度號
KX-HA-FFP fluoroplastic ene insulation and sheath copper wire braided total shielding precision grade K graduation number
熱電偶用補償電纜 安徽中盛電氣集團有限公司
Compensation cables for thermocouples
KX-HA-FFRP 氟塑料烯絕緣和護套銅絲編織總屏蔽精密級K分度號
KX-HA-FFRP fluoroplastic ene insulation and sheath copper wire braided total shielding precision grade K graduation number
熱電偶用補償軟電纜
Compensating flexible cables for thermocouples
KX-HA-FVRP 氟塑料烯絕緣聚氯乙烯護套銅絲編織總屏蔽精密級K
KX-HA-FVRP fluoroplastic vinyl insulation polyvinyl chloride sheath copper wire braided total shielding precision grade K
分度號熱電偶用補償軟電纜
Compensating flexible cable for graduated thermocouples
KX-HA-FPVP 氟塑料絕緣聚氯乙烯護套銅絲編織分屏加總屏蔽精密 安徽中盛電氣集團有限公司
KX-HA-FPVP fluoroplastic insulation, polyvinyl chloride sheath, copper wire braided split screen, total shielding precision
級K分度號熱電偶用補償電纜
Compensation cables for K-grade thermocouples
KX-HA-FPVRP 氟塑料絕緣聚氯乙烯護套銅絲編織分屏加總屏蔽精密
KX-HA-FPVRP fluoroplastic insulation, polyvinyl chloride sheath, copper wire braided split screen, total shielding precision
級K分度號熱電偶用補償軟電纜
Compensating flexible cables for K-grade thermocouples
KX-HA-FGP 氟塑料烯絕緣硅橡膠護套銅絲編織總屏蔽精密級K分
KX-HA-FGP fluoroplastic ene insulation silicone rubber sheath copper wire braided total shielding precision grade K score
度號熱電偶用補償電纜
Compensation cable for degree thermocouple
KX-HA-FGRP 氟塑料烯絕緣硅橡膠護套銅絲編織總屏蔽精密級K分
KX-HA-FGRP fluoroplastic vinyl insulation silicone rubber sheath copper wire braided total shielding precision grade K score
度號熱電偶用補償軟電纜
Compensating flexible cable for degree thermocouple
KX-HA-FPGP 氟塑料絕緣硅橡膠護套銅絲編織分屏加總屏蔽精密級
KX-HA-FPGP fluoroplastic insulation silicone rubber sheath copper wire braided split screen total shielding precision level
K分度號熱電偶用補償電纜
Compensation cable for K-grade thermocouple
KX-HA-FPGRP 氟塑料絕緣硅橡膠護套銅絲編織分屏加總屏蔽精密級
KX-HA-FPGRP fluoroplastic insulation silicone rubber sheath copper wire braided split screen total shielding precision level
K分度號熱電偶用補償軟電纜
Compensation flexible cable for K-grade thermocouple
注：1以上基本型號僅列出銅絲或鍍錫絲屏蔽方式，其他屏蔽類
Note: The above basic models only list copper wire or tin wire shielding methods, other shielding types
型型號只需改變屏蔽代號即可，如P2、P3
The model only needs to change the shielding code, such as P2, P3
2 阻燃型在型號前加ZR，鎧裝電纜型號后加22，ZR192為進口
Add ZR before the model for flame-retardant type 2, add 22 after the armored cable model, and import ZR192
PFA材料，耐溫260℃
PFA material, temperature resistant to 260 ℃
4：本安型補償電纜
4: Intrinsically safe compensating cable
IA-KX-GA-FPVP 氟塑料絕緣聚氯乙烯護套銅絲編織分屏加總屏蔽精密 安徽中盛電氣集團有限公司
IA-KX-GA-FPVP Fluoroplastic Insulation PVC Sheath Copper Wire Braided Split Screen Plus Precision Shielding
級K分度號本安型熱電偶用補償電纜
Compensation cable for intrinsically safe thermocouples with K-grade division number
IA-KX-GA-FPVRP 氟塑料絕緣聚氯乙烯護套銅絲編織分屏加總屏蔽精密
IA-KX-GA-FPVRP Fluoroplastic Insulation PVC Sheath Copper Wire Braided Split Screen Plus Precision Shielding
級K分度號本安型熱電偶用補償軟電纜 安徽中盛電氣集團有限公司
Compensation flexible cable for intrinsically safe thermocouples with K-grade division number
IA-KX-HA-FPFP 氟塑料絕緣和護套銅絲編織分屏加總屏蔽精密級K分
IA-KX-HA-FPFP Fluoroplastic Insulation and Sheath Copper Wire Braided Split Screen with Total Shielding Precision Grade K Score
度號本安型熱電偶用補償電纜
Compensation cables for intrinsically safe thermocouples with degree codes
IA-KX-HA-FPFRP 氟塑料絕緣和護套銅絲編織分屏加總屏蔽精密級K分
IA-KX-HA-FPFRP Fluoroplastic Insulation and Sheath Copper Wire Braided Split Screen with Total Shielding Precision Grade K Score
