AFFRP耐油高溫電纜：高強度氟塑料高溫電纜
應用：適用于冶金、石油、化工、鐵路以及發電廠等工礦企業，在高溫條件下和惡劣環境中（如酸、堿、油水、低溫條件）作為各種電器，儀表及自動裝置之連接線，公交流額定電壓450、750V及一下的控制、監控以及保護電路等場合下使用
AFFRP oil resistant and high-temperature cable: high-strength fluoroplastic high-temperature cable AFFP3 * 0.5, AFFRP3 * 0.35, AFPF, AFRPF application: suitable for metallurgical, petroleum, chemical, railway, and power plants and other industrial and mining enterprises. It is used as a connection line for various electrical appliances, instruments, and automatic devices in high temperature conditions and harsh environments (such as acid, alkali, oil-water, and low temperature conditions). It is used in control, monitoring, and protection circuits for bus flow rated voltages of 450, 750V, and below
AFFRP耐油高溫電纜：
AFFRP oil and high temperature resistant cable:
高強度氟塑料高溫電纜AFFP3*0.5、AFFRP3*0.35、AFPF、AFRPF
High strength fluoroplastic high-temperature cable AFFP3 * 0.5 AFFRP3*0.35、AFPF、AFRPF
應用：適用于冶金、石油、化工、鐵路以及發電廠等工礦企業，在高溫條件下和惡劣環境中（如酸、堿、油水、低溫條件）作為各種電器，儀表及自動裝置之連接線，公交流額定電壓450、750V及一下的控制、監控以及保護電路等場合下使用。
Application: Suitable for industrial and mining enterprises such as metallurgy, petroleum, chemical industry, railways, and power plants. It is used as a connecting wire for various electrical appliances, instruments, and automatic devices in high temperature conditions and harsh environments (such as acid, alkali, oil-water, and low temperature conditions). It is also used in control, monitoring, and protection circuits for bus flow rated voltages of 450, 750V, and below.
AFFRP耐高溫電纜結構參數及導體直流電阻
Structural parameters and conductor DC resistance of AFFRP high-temperature resistant cables
導體標稱截面mm2 | 導體結構根數／直徑mm | 電纜絕緣外徑mm | 20℃時導體電阻不大于Ω/km | 計算重量kg/km | ||||||||
AF-250 | AFP-250 | AF-250 | AFP-250 | |||||||||
250V | 600V | 250V | 600V | 250V | 600V | 250V | 600V | |||||
zui小 | zui大 | zui小 | zui大 | zui大 | zui大 | 鍍銀 | ||||||
0.06 | 7/0.10 | 0.55 | 0.65 | 0.70 | 0.90 | 1.15 | 1.40 | 336.0 | 1.13 | 1.7 | 4.1 | 4.6 |
0.08 | 7/0.12 | 0.60 | 0.70 | 0.75 | 0.95 | 1.20 | 1.45 | 227.0 | 1.40 | 2.0 | 4.9 | 5.7 |
0.12 | 7/0.15 | 0.70 | 0.80 | 0.85 | 1.05 | 1.30 | 1.60 | 145.0 | 2.0 | 2.7 | 6.3 | 7.0 |
0.2 | 7/0.20 | 0.85 | 0.95 | 1.00 | 1.20 | 1.50 | 1.80 | 83.5 | 3.1 | 3.9 | 7.4 | 8.1 |
0.35 | 19/0.15 | 1.00 | 1.10 | 1.15 | 1.35 | 1.70 | 2.00 | 53.4 | 4.3 | 5.3 | 10.4 | 11.3 |
0.5 | 19/018 | 1.15 | 1.25 | 1.30 | 1.50 | 1.85 | 2.10 | 37.8 | 6.1 | 6.9 | 11.6 | 13.2 |
0.75 | 19/0.23 | 1.55 | 1.70 | 1.65 | 1.90 | 2.25 | 2.50 | 22.7 | 11.2 | 11.4 | 19.3 | 19.8 |
1.0 | 19/0.26 | 1.70 | 1.85 | 1.75 | 2.10 | 2.40 | 2.70 | 19.0 | 12.5 | 14.1 | 20.7 | 23.0 |
1.5 | 19/0.32 | 2.05 | 2.40 | 3.00 | 11.7 | 19.9 | 30.9 | |||||
2.0 | 19/0.37 | 2.30 | 2.60 | 3.20 | 9.45 | 24.7 | 36.0 | |||||
2.5 | 37/0.30 | 2.90 | 3.30 | 4.00 | 6.86 | 33.2 | 45.7 | |||||
3.0 | 37/0.32 | 3.05 | 3.45 | 4.20 | 6.23 | 37.8 | 51.5 | |||||
4.0 | 37/0.37 | 3.40 | 3.80 | 4.60 | 4.51 | 47.7 | 64.4 | |||||
5.0 | 37/0.41 | 3.70 | 4.05 | 4.90 | 3.90 | 57.2 | 76.3 | |||||
6.0 | 37/0.45 | 3.95 | 4.35 | 5.20 | 3.05 | 67.4 | 88.7 | |||||
