- 產品名稱：Motor winding lead wire JBQ
- 瀏覽：
- 添加時間：2024-07-19 10:18:53
- 推薦度：
連續運行導體zui高溫度為70℃的電機繞組引接線
Wire connection for motor winding with the highest temperature of 70 ℃ for continuous operation of conductor
一、執行標準：
1、 Execution standards:
JB6213 92 Q／12YJ 4135-2000
JB6213 92 Q／12YJ 4135-2000
二、適用范圍：
2、 Scope of application:
適用于交流額定電壓6000V及以下的電機繞組的引出連接用。
Suitable for the lead out connection of motor windings with AC rated voltage of 6000V and below.
三、使用特性：
3、 Usage characteristics:
電線導體的*允許工作溫度應不超過70℃。具有良好的柔軟性及耐熱、耐溶劑性。
The allowable working temperature of the wire conductor should not exceed 70 ℃. Has good flexibility, heat resistance, and solvent resistance.
四、JBQ電纜50mm2 JBQ1140V電纜型號和名稱：
4、 JBQ cable 50mm2 JBQ1140V cable model and name:
JF(JBF) 銅芯聚氯乙烯復合物絕緣電機繞組引接電纜(電線)
JF (JBF) copper core polyvinyl chloride composite insulated motor winding lead cable (wire)
JV(JBV) 銅芯聚氯乙烯絕緣電機繞組引接電纜(電線)
JV (JBV) copper core PVC insulated motor winding lead cable (wire)
JXN(JBQ) 銅芯橡皮絕緣護套電機繞組引接軟電纜(電線)
JXN (JBQ) copper core rubber insulated sheathed motor winding connection flexible cable (wire)
JXF(JBHF) 銅芯橡皮絕緣氯丁護套電機繞組引接軟電纜(電線)
JXF (JBHF) copper core rubber insulated chloroprene sheathed motor winding connection flexible cable (wire)
用途
purpose
該型號產品為交流額定電壓1140V及以下的B級絕緣電機、電器繞組連接并引出機殼或繞組與電機殼體上的接線柱連接用電線。
This model of product is a B-class insulated motor with an AC rated voltage of 1140V or below. It is used to connect the electrical windings and lead them out of the casing or to connect the windings to the terminal posts on the motor casing.
型號及名稱
Model and Name
JBQ 橡皮絕緣護套引接線
JBQ rubber insulation sheath lead wire
1 鍍錫銅導體
1 Tin plated copper conductor
2 隔離層(如果有的話)
2 isolation layers (if any)
3 橡皮絕緣層
3 rubber insulation layer
4 橡皮護套層
4 rubber sheath layer
(注：本產品可根據用戶需要制成黑、白、綠和紅等多種顏色
(Note: This product can be made in various colors such as black, white, green, and red according to user needs)
型號及名稱
Model and Name
JBQ 橡皮絕緣護套引接線
JBQ rubber insulation sheath lead wire
1 鍍錫銅導體
1 Tin plated copper conductor
2 隔離層(如果有的話)
2 isolation layers (if any)
3 橡皮絕緣層
3 rubber insulation layer
4 橡皮護套層
4 rubber sheath layer
(注：本產品可根據用戶需要制成黑、白、綠和紅等多種顏色，
(Note: This product can be made into various colors such as black, white, green, and red according to user needs.),
色澤鮮明、持久)
Bright and long-lasting color
產品結構及參考數據
Product Structure and Reference Data
JBQ型500V
JBQ type 500V
標稱截面(mm2) 導電線芯結構(mm) 絕緣標稱厚度
Nominal cross-section (mm2) Conductive core structure (mm) Insulation nominal thickness
(mm) 護套標稱厚度
(mm) nominal thickness of sheath
(mm) 電纜zui大外徑
(mm) Cable with the largest outer diameter
(mm) 電纜參考重量(kg/km) 20℃導體電阻≤(Ω/km)
(mm) Cable reference weight (kg/km) 20 ℃ conductor resistance ≤ (Ω/km)
單線根數 單線直徑
Number of single wires, diameter of single wire
0.5 28 0.15 0.6 0.8 4.3 20 38.5
0.75 42 0.15 0.6 0.8 4.5 24 25.7
1.0 32 0.20 0.6 0.8 4.7 28 18.9
1.5 48 0.20 0.6 0.8 5.0 35 12.6
2.5 19 0.41 0.8 1.0 6.2 57 7.59
4 19 0.52 0.8 1.0 6.8 76 4.54
6 19 0.64 0.8 1.0 4.5 100 3.00
10 49 0.52 1.0 1.2 10.0 178 1.78
16 49 0.64 1.0 1.2 11.2 243 1.18
25 98 0.58 1.0 1.4 13.7 372 0.716
35 133 0.58 1.0 1.4 14.8 471 0.528
50 133 0.68 1.2 1.6 17.1 647 0.384
70 189 0.68 1.2 1.6 19.6 879 0.270
95 259 0.68 1.4 1.6 21.9 1160 0.197
120 259 0.76 1.6 1.8 24.6 1451 0.158
150 320 0.76 1.8 2.2 29 1911.5 0.132
185 395 0.76 1.8 2.2 32 2268.65 0.108
240 513 0.76 2.2 3 35 3010 0.0817
300 641 0.76 2.4 3.5 38 3770 0.0654
