組合電纜SYV75-5+RVV+RVVP
Composite cable SYV75-5+RVV+RVVP
組合電纜的詳細介紹：組合電纜 SYV75-5+RVV+RVVP高溫組合電纜產品具有結構緊密、性能穩定、安裝方便，廣泛用于通訊、導航、電子對抗、預警系統、各種測試設備用綜合電纜?？筛鶕?jù)用戶要求將電源線、低壓信號線、屏蔽線、高頻電纜等多根導線組合成一根電纜。
Detailed introduction of composite cable: The SYV75-5+RVV+RVVP high-temperature composite cable product has a compact structure, stable performance, and easy installation. It is widely used as a comprehensive cable for communication, navigation, electronic countermeasures, early warning systems, and various testing equipment. Multiple wires such as power lines, low-voltage signal lines, shielded wires, and high-frequency cables can be combined into one cable according to user requirements.
3*0.5+4*0.75+2*0.5
3*0.5+4*0.75+2*0.5
為適應高科技及各種科研的需要,組織了科技人員與使用單位共同努力,開發了一系列組合電纜。產品具有結構緊密、性能穩定、安裝方便，廣泛用于通訊、導航、電子對抗、預警系統、海洋勘探、各種測試設備用綜合電纜。可根據用戶要求將多根信號線、電源線、屏蔽線、同軸射頻電纜等組合成一根可帶總屏蔽的組合電纜。
In order to meet the needs of high technology and various scientific research, a series of composite cables have been developed through the joint efforts of scientific and technological personnel and user units. The product has a compact structure, stable performance, and easy installation, and is widely used in communication, navigation, electronic countermeasures, early warning systems, marine exploration, and various testing equipment as a comprehensive cable. Multiple signal lines, power lines, shielded wires, coaxial RF cables, etc. can be combined into a composite cable with total shielding according to user requirements.
視頻線SYV-75-5,SYV-75-3,電源線RVV,屏蔽線RVVP 供應視頻線SYV-75-5,SYV-75-3,電源線RVV,屏蔽線RVVP 信息標題: 供應視頻線SYV-75-5,SYV-75-3,電源線RVV,屏蔽線RVVP
Video lines SYV-75-5, SYV-75-3, power line RVV, shielded line RVVP supply video lines SYV-75-5, SYV-75-3, power line RVV, shielded line RVVP information title: Supply video lines SYV-75-5, SYV-75-3, power line RVV, shielded line RVVP
SYV-75-3 SYV-75-5 SYV-75-7 SYV-75-9 SYV-50-3 SYV-50-5
SYV-75-3 SYV-75-5 SYV-75-7 SYV-75-9 SYV-50-3 SYV-50-5
SYWV-75-5+HYV2×2×1/0.5組合網絡電纜參照SJ/T11138-1997、YD/T322-1996標準設計制造。
The SYWV-75-5+HYV2 × 2 × 1/0.5 combination network cable is designed and manufactured in accordance with SJ/T11138-1997 and YD/T322-1996 standards.
該產品具有物理發泡射頻同軸電纜和對稱電纜的傳輸特點。適用于傳輸1GHz及以下的射頻信號，傳輸音頻150KHz及以下的模擬信號2048kbit/s及以數字信號。
This product has the transmission characteristics of physical foam RF coaxial cable and symmetrical cable. Suitable for transmitting RF signals of 1GHz and below, analog signals of 150KHz and below at 2048kbit/s, and digital signals.
| 結構尺寸 |
型號規格 Model specifications 結構組成 Structural composition 內導體結構 Internal conductor structure 外徑 external diameter 絕緣 insulation 外徑 external diameter 外導體 External conductor 線纜 Cable 外徑 external diameter 護層 Protective layer 外徑 external diameter SYWV-75-5+HYV SYWV-75-5+HYV 2×2×1／0.5 2×2×1／0.5 SYWV-75-5 SYWV-75-5 1×1.0 1×1.0 4.8 four point eight 鋁塑帶縱包＋編織 Aluminum plastic strip longitudinal wrapping+weaving ≯5.6 ≯5.6 7.2 seven point two HYV 2×2×1/0.5 HYV 2 × 2 × 1/0.5 1×0.5 1×0.5 0.9 zero point nine -- -- ≯2.4 ≯2.4 4.3 four point three SYWV-75-5-4P+HSYV5 SYWV-75-5-4P+HSYV5 4×2×1／0.51 4×2×1／0.51 SYWV-75-5-4P SYWV-75-5-4P 1×1.02 1×1.02 4.57 four point five seven 自粘鋁塑帶縱包＋編織＋ Self adhesive aluminum-plastic tape longitudinal wrapping+weaving+ 雙面鋁塑帶縱包＋編織 Double sided aluminum-plastic tape longitudinal wrapping+weaving ≯6.0 ≯6.0 7.6 seven point six HSYV5 4×2×1/0.51 HSYV5 4 × 2 × 1/0.51 1×0.51 1×0.51 0.91 zero point nine one -- -- ≯5.4 ≯5.4 7.2 seven point two RG6+HSYV5 RG6+HSYV5 2×2×1／0.51(充油) 2 × 2 × 1/0.51 (oil filled) RG6 RG6 1×1.02 1×1.02 4.57 four point five seven 雙面鋁塑帶縱包＋編織＋ Double sided aluminum-plastic tape longitudinal package+weaving+ 雙面鋁塑帶縱包 Double sided aluminum-plastic tape longitudinal package ≯5.8 ≯5.8 7.4 seven point four HSYV5 2×2×1/0.51 HSYV5 2 × 2 × 1/0.51 1×0.51 1×0.51 0.91 zero point nine one -- -- ≯2.4 ≯2.4 4.5 four point five
同軸電纜參考性能 Reference performance of coaxial cable 額定特性阻抗(Ω) Rated characteristic impedance (Ω) 75 seventy-five 額定速比(%) Rated speed ratio (%) 84 eighty-four 額定電容(pF／m) Rated capacitance (pF/m) 53 fifty-three ***大衰減 Maximum attenuation (20℃) (20℃) (dB/100m) (dB/100m) 5MHz 5MHz 1.87 one point eight seven 55MHz 55MHz 4.94 four point nine four 100MHZ 100MHZ 7.20 seven point two zero 300MHz 300MHz 11.25 eleven point two five 350MHz 350MHz 12.63 twelve point six three 600MHz 600MHz 16.23 sixteen point two three 860MHz 860MHz 19.99 nineteen point nine nine 1000MHZ 1000MHZ 21.46 twenty-one point four six 回波損耗 Return loss (5～1000MHz) (5～1000MHz) ≥20dB ≥20dB
HYV型雙絞線電氣性能 Electrical performance of HYV twisted pair cable 額定電容(nF／km) Rated capacitance (nF/km) 52 fifty-two 導體直流電阻不平衡度(***大） Unbalance degree of conductor DC resistance (maximum) 5% 5% 標稱直流電阻(Ω／km) Nominal DC resistance (Ω/km) 95 ninety-five 遠端串音防衛度150KHz(dB／km) Remote Crosstalk Defense 150KHz (dB/km) ＞68 ＞68 HYV型雙絞線電氣性能 Electrical performance of HYV twisted pair cable 導體直流電阻(Ω／km) Direct current resistance of conductor (Ω/km) ＜93 ＜93 導體直流電阻不平衡度 Unbalanced DC resistance of conductor ＜2% ＜2% 絕緣電阻(MΩ／km) Insulation resistance (M Ω/km) ＞8000 ＞8000 電容(nF／km) Capacitor (nF/km) 45±5 45±5 ***大衰減 Maximum attenuation (dB/km) (dB/km) 1MHz 1MHz 1.70 one point seven zero 100MHz 100MHz 9.00 nine 100MHZ 100MHZ 24.00 twenty-four 阻 抗 Impedance 100±15 100±15 工程使用數據 Engineering usage data 彎曲半徑 Bending radius (cm) 室 內 Indoor 4.5 four point five 室 外 Outdoor 8.5 eight point five 交貨長度 Delivery length (m) 100 one hundred 200 two hundred |
