- 產品名稱：High temperature variable frequency cableBPFFP
- 瀏覽：
- 添加時間：2024-07-23 17:22:44
- 推薦度：
BPFFP變頻電力電纜適用于交流額定電壓0.6/1KV及以下變頻控制系統作供電電纜或電氣連接，產品具有較強的耐電壓沖擊性，能經受變頻時的脈沖電壓，電纜具有良好的屏蔽性，并有效消除電磁干擾，降低變頻電機噪音，保證系統穩定運行。廣泛用于冶金、電力、石化等行業。
BPFFP variable frequency power cable is suitable for use as a power cable or electrical connection in AC rated voltage 0.6/1KV and below variable frequency control systems. The product has strong resistance to voltage shock and can withstand pulse voltage during variable frequency conversion. The cable has good shielding and effectively eliminates electromagnetic interference, reduces the noise of variable frequency motors, and ensures stable system operation. Widely used in industries such as metallurgy, power, and petrochemicals.
BPFFP變頻電力電纜產品執行標準
BPFFP Variable Frequency Power Cable Product Execution Standard
Q/HHTZH006
Q/HHTZH006
阻燃耐火特性試驗執行GB12666-90標準
The flame retardant and fire-resistant characteristics test shall comply with GB12666-90 standard
BPFFP變頻電力電纜使用特性
Usage characteristics of BPFFP variable frequency power cable
1． 交流額定電壓：U0/U 0.6/1KV
1. Rated AC voltage: U0/U 0.6/1KV
zui高工作溫度：硅橡膠絕緣180℃
Zui High Operating Temperature: Silicone Rubber Insulation 180 ℃
氟46絕緣200℃和260℃兩種
Fluorine 46 insulation at 200 ℃ and 260 ℃
聚氯乙烯絕緣70℃
Polyvinyl chloride insulation at 70 ℃
交聯聚乙烯90℃
Cross linked polyethylene at 90 ℃
zui低環境溫度：敷設電纜時的環境溫度應不低于-40℃；聚氯乙烯護套電纜不低于0℃。
Zui low ambient temperature: The ambient temperature during cable laying should not be lower than -40 ℃; PVC sheathed cables shall not be lower than 0 ℃.
2． 電纜安裝敷設溫度應不低于-25℃。
2. The temperature for cable installation and laying should not be lower than -25 ℃.
3． 電纜允許彎曲半徑：電纜zui小為電纜外徑的10倍
3. Allowable bending radius for cables: The minimum allowable bending radius for cables is 10 times the outer diameter of the cable
型號
model
名稱
name
BPFFP
BPFFP
氟46絕緣和護套銅絲編織屏蔽耐高溫變頻電纜。
Fluorine-46 insulated and sheathed copper wire braided shielded high-temperature resistant variable frequency cable.
BPFFP2
BPFFP2
氟46絕緣和護套銅帶繞包屏蔽耐高溫變頻電纜。
Fluorine-46 insulated and sheathed copper tape wrapped shielded high temperature resistant variable frequency cable.
BPFFPP2
BPFFPP2
氟46絕緣和護套銅絲編織銅帶繞包屏蔽耐高溫變頻電纜
Fluorine-46 insulated and sheathed copper wire braided copper tape wrapped shielding high-temperature resistant variable frequency cable
BPFFP3
BPFFP3
氟46絕緣和護套鋁聚酯復合膜繞包屏蔽耐高溫變頻電纜。
Fluorine-46 insulated and sheathed aluminum polyester composite film wrapped shielding high temperature resistant variable frequency cable.
BPVVP
BPVVP
聚氯乙烯絕緣和護套銅絲編織屏蔽變頻電纜。
PVC insulated and sheathed copper wire braided shielded variable frequency cable.
BPVVP2
BPVVP2
聚氯乙烯絕緣和護套銅帶繞包屏蔽變頻電纜。
PVC insulated and sheathed copper tape wrapped shielded variable frequency cable.
BPVVPP2
BPVVPP2
聚氯乙烯絕緣和護套銅絲編織銅帶繞包屏蔽變頻電纜。
PVC insulated and sheathed copper wire braided copper tape wrapped shielded variable frequency cable.
BPVVP3
BPVVP3
聚氯乙烯絕緣和護套鋁聚酯復合膜繞包屏蔽變頻電纜。
PVC insulated and sheathed aluminum polyester composite film wrapped shielded variable frequency cable.
BPYJVP
BPYJVP
交聯聚乙烯絕緣聚氯乙烯護套銅絲編織屏蔽變頻電纜。
Cross linked polyethylene insulated polyvinyl chloride sheathed copper wire braided shielded variable frequency cable.
BPYJVP2
BPYJVP2
交聯聚乙烯絕緣聚氯乙烯護套銅帶繞包屏蔽變頻電纜。
Cross linked polyethylene insulated polyvinyl chloride sheathed copper tape wrapped shielded variable frequency cable.
BPYJVPP2
BPYJVPP2
交聯聚乙烯絕緣聚氯乙烯護套銅絲編織銅帶繞包屏蔽變頻電纜。
Cross linked polyethylene insulated polyvinyl chloride sheathed copper wire braided copper tape wrapped shielded variable frequency cable.
BPYJVP3
BPYJVP3
交聯聚乙烯絕緣聚氯乙烯護套鋁聚酯復合膜繞包屏蔽變頻電纜。
Cross linked polyethylene insulated polyvinyl chloride sheathed aluminum polyester composite film wrapped shielded variable frequency cable.
備注：導體線芯中銅絲可以采用鍍錫，阻燃型電纜型號前加ZR，軟結構電纜加R。
Note: The copper wire in the conductor core can be tinned, ZR can be added to the front of flame-retardant cable models, and R can be added to flexible structure cables.
代號
Code name
代號含義
Meaning of code
BP
BP
變頻電力電纜
Variable frequency power cable
銅導體
Copper conductor
省略
ellipsis
G
G
硅橡膠絕緣或護套
Silicone rubber insulation or sheath
F
F
F46絕緣或護套
F46 insulation or sheath
V
V
聚氯乙烯絕緣或護套
Polyvinyl chloride insulation or sheath
YJ
YJ
交聯聚乙烯絕緣
Cross linked polyethylene insulation
VF
VF
P（P1）
P（P1）
銅編織屏蔽（鍍錫編織屏蔽）
Copper braided shielding (tin plated braided shielding)
P2
P2
銅帶繞包屏蔽
Copper tape wrapped shielding
P3
P3
鋁聚酯復合膜繞包屏蔽
Aluminum polyester composite film wrapped shielding
PP2
PP2
銅絲編織銅帶繞包屏蔽
Copper wire braided copper tape wrapped shielding
