一、安裝線執行標準
1、 Installation line execution standard
Q／12YJ3157—2000
Q／12YJ3157—2000
二．安裝線適用范圍：
2、 Scope of application of installation line:
適于交流額定電壓5DOV及以下或直流1000V及以下電氣設備及低壓線路安裝用線。
Suitable for the installation of electrical equipment and low-voltage lines with rated AC voltage of 5DOV or below or DC voltage of 1000V or below.
三．使用特性：
3、 Usage characteristics:
安裝線線芯的長期工作溫度應不超過70℃。 同時適用于低溫條件下使用。其安裝環境溫度應不低干-40℃。安截面不同．電線能經受7000～9000V火花電壓試驗，且具有耐寒耐油和耐燃性能。
The long-term working temperature for installing wire cores should not exceed 70 ℃. Suitable for use under low temperature conditions. The installation environment temperature should not be lower than -40 ℃. The cross-sectional area is different. The wire can withstand a spark voltage test of 7000-9000V and has cold resistance, oil resistance, and flame resistance properties.
四．安裝線型號 名稱:
4、 Installation line model name:
AVF 銅芯丁腈-聚氯乙烯復合物絕緣安裝線。
AVF Copper core nitrile polyvinyl chloride composite insulated installation wire.
AVFR 銅芯丁腈一聚氯乙烯復臺物絕緣安裝軟線。
AVFR Copper core nitrile polyvinyl chloride composite insulation installation flexible wire.
