BPYJVPP2變頻電纜由變頻器,變頻器用供電電纜和頻率控制電機組成了的傳動系統。它用于頻率控制傳動系統中作供電電纜或連接電纜。該系統的電纜尤其適用于造紙、鋼鐵、紡織、金屬加工和食品加工工業用×泵、鼓風機、輸送機、傳輸線和空調等

The BPYJVPP2 frequency conversion cable is a transmission system composed of a frequency converter, a power supply cable for the frequency converter, and a frequency control motor. It is used as a power cable or connecting cable in frequency control transmission systems. The cables of this system are particularly suitable for pumps, blowers, conveyors, transmission lines, and air conditioners used in the paper, steel, textile, metal processing, and food processing industries.

BPYJVPP2變頻電纜型號規格

BPYJVPP2 Variable Frequency Cable Model and Specifications

BPYJVTP2

BPYJVTP2

銅芯交聯聚乙烯絕緣聚氯乙烯護套銅絲纏繞+銅帶繞包屏蔽變頻電纜

Copper core cross-linked polyethylene insulated polyvinyl chloride sheathed copper wire winding+copper tape winding shielded variable frequency cable

requency converter cable with Cu core, XLPE insulation, PVC sheath, copper wire winding plus coppe tape wrapping shielding

requency converter cable with Cu core, XLPE insulation, PVC sheath, copper wire winding plus coppe tape wrapping shielding

ZR-BPYJVTP2

ZR-BPYJVTP2

銅芯交聯聚乙烯絕緣阻燃聚氯乙烯護套銅絲纏繞+銅帶繞包屏蔽阻燃型變頻電纜

Copper core cross-linked polyethylene insulated flame-retardant polyvinyl chloride sheathed copper wire winding+copper tape winding shielded flame-retardant variable frequency cable

Flame retardant type frequency converter cable with Cu core, XLPE insulation, ?  ame retardant PVC sheath, copper wire winding plus copper tape wrapping shielding

Flame retardant type frequency converter cable with Cu core, XLPE insulation, ?  ame retardant PVC sheath, copper wire winding plus copper tape wrapping shielding

BPYJVP12R

BPYJVP12R

銅芯交聯聚乙烯絕緣聚氯乙烯護套銅帶繞包+銅絲編織雙屏蔽變頻軟電纜

Copper core cross-linked polyethylene insulated polyvinyl chloride sheathed copper tape winding+copper wire braided double shielded variable frequency flexible cable

Frequency Converter soft cable with Cu core, XLPE insulation, PVC sheath, copper tape wrapping pluscopper wire braided dual shielding

Frequency Converter soft cable with Cu core, XLPE insulation, PVC sheath, copper tape wrapping pluscopper wire braided dual shielding

ZR-BPYJVP12 R

ZR-BPYJVP12 R

銅 芯交聯聚乙烯絕緣阻燃聚氯乙烯護套銅帶繞包+銅絲編織雙屏蔽阻燃型變頻軟電纜lame retardant type frequency converter soft cable with Cu core, XLPE insulation, ?  ame retardant PVCsheath, copper tape wrapping plus copper wire braided dual shielding

Copper core cross-linked polyethylene insulation flame-retardant polyvinyl chloride sheath copper tape winding+copper wire weaving double shielding flame-retardant frequency converter soft cable with Cu core, XLPE insulation, ?  ame retardant PVCsheath, copper tape wrapping plus copper wire braided dual shielding

BPYJVPX13R

BPYJVPX13R

銅芯交聯聚乙烯絕緣聚氯乙烯護套鋁帶繞包+鍍錫銅絲編織雙屏蔽變頻軟電纜

Copper core cross-linked polyethylene insulated polyvinyl chloride sheathed aluminum tape winding+tinned copper wire braided double shielded variable frequency flexible cable

Frequency converter soft cable with Cu core, XLPE insulation, PVC sheath, aluminum tape wrapping plus tinned copper wire braided dual shielding

Frequency converter soft cable with Cu core, XLPE insulation, PVC sheath, aluminum tape wrapping plus tinned copper wire braided dual shielding

ZR-BPYJVPX13R

ZR-BPYJVPX13R

銅 芯交聯聚乙烯絕緣阻燃聚氯乙烯護套鋁帶繞包+鍍錫銅絲編織雙屏蔽阻燃型變頻軟電纜lame retardant type frequency converter soft cable with Cu core, XLPE insulation, ?  ame retardant PVCsheath, aluminum tape wrapping plus tinned copper wire braided dual shielding

Copper core cross-linked polyethylene insulated flame-retardant polyvinyl chloride sheathed aluminum tape winding+tinned copper wire braided double shielded flame-retardant frequency converter soft cable with Cu core, XLPE insulation, ?  ame retardant PVCsheath, aluminum tape wrapping plus tinned copper wire braided dual shielding

產品特點：

Product features:

l、 較低的有效電容;

l、  Lower effective capacitance;

2、 具有屏蔽性能;

2. Has shielding performance;

3、 良好的耐火燃燒性能，可用于危險區域;

3. Good fire resistance and combustion performance, suitable for use in hazardous areas;

4、 低傳輸阻抗：該電纜含有屏蔽層，以防止電磁干擾，傳輸阻抗RX是對屏蔽抗感應和電容耦合的有效性的度量，低傳輸阻抗可提供良好的電磁相容性;2、 交聯聚乙烯絕緣， 耐溫耐候性好。

4. Low transmission impedance: The cable contains a shielding layer to prevent electromagnetic interference, and the transmission impedance RX is a measure of the effectiveness of shielding against induction and capacitive coupling. Low transmission impedance can provide good electromagnetic compatibility; 2. Cross linked polyethylene insulation has good temperature and weather resistance.

5、 低傳輸阻抗， 電磁兼容性好。

5. Low transmission impedance, good electromagnetic compatibility.

6、 低工作電容。

6. Low working capacitance.

7、 良好的抗干擾和低輻射性能。

7. Good anti-interference and low radiation performance.

8、 對稱的三芯電纜結構設計， 具有比四芯電纜更好的傳輸性能。對稱的三芯設計，更好的電磁相容性，比四芯電纜更好的性能。三根耐候耐溫樹脂絕緣線芯在縫隙處均勻等距絞合，形成一種真正的同心結構。

8. The symmetrical three core cable structure design has better transmission performance than four core cables. Symmetrical three core design, better electromagnetic compatibility, and better performance than four core cables. Three weather resistant and temperature resistant resin insulated wire cores are evenly and equally twisted at the gaps, forming a true concentric structure.

3+1 結構

規格	近似外徑mm	重量kg/km	電纜載流量A
3×4+1×2.5	16.0	334	34
3×6+1×4	17.3	430	45
3×10+1×6	20.2	627	53
3×16+1×10	22.7	833	84
3×25+1×16	27.4	1308	109
3×35+1×16	28.9	1718	132
3×50+1×25	30.2	3059	159
3×70+1×35	32.8	3445	195
3×95+1×50	34.9	4172	237
3×120+1×70	39.6	5055	274
3×150+1×70	44.2	5410	310
3×185+1×95	48.5	7062	355
3×240+1×120	54.6	9811	416

 3+3 結構

規格	近似外徑mm	重量kg/km	電纜載流量A
3×2.5+3×0.5	12.5	232	26
3×4+3×0.75	14.0	330	34
3×6+3×1.0	15.4	422	45
3×10+3×1.5	19.6	621	53
3×16+3×2.5	22.7	820	84
3×25+3×4	28.0	1310	109
3×35+3×6	29.4	1723	132
3×50+3×10	36.3	3075	159
3×70+3×10	40.0	3454	195
3×95+3×16	45.5	4180	237
3×120+3×16	50.4	5100	274
3×150+3×25	55.5	5432	310
3×185+3×25	60.6	7098	355

允許溫度及工作電壓

Allowable temperature and operating voltage

1、 允許導體連續工作zui高溫度120℃，短路時zui高溫度180℃;

1. Allow the conductor to operate continuously at a maximum temperature of 120 ℃, and during a short circuit at a maximum temperature of 180 ℃;

2、 在運輸、儲存、輻射、搬運和作業時自由彎曲≥+5℃，固定敷設：≥-10℃;

2. Free bending ≥+5 ℃ during transportation, storage, radiation, handling, and operation, fixed laying: ≥ -10 ℃;

3、 額定電壓為600/1000V，交流試驗電壓3500V。

3. The rated voltage is 600/1000V, and the AC test voltage is 3500V.

技術數據

technical data

1、 按DIN VDE第5類的軟絞合銅導體;

1. Flexible stranded copper conductor according to DIN VDE Class 5;

2、 耐候耐溫樹脂絕緣;

2. Weather resistant and temperature resistant resin insulation;

3、 軟超屏蔽層。

3. Soft ultra shielding layer.
