- 產品名稱：High temperature resistant silver plated PTFE wire AF-250
- 瀏覽：
- 添加時間：2025-03-25 10:33:25
- 推薦度：
航空用聚四氟乙烯絕緣和氟46絕緣電纜
Polytetrafluoroethylene insulated and Fluorine-46 insulated cables for aviation use
適用范圍
scope of application
適用于航空工業和電子工業中交流額定電壓600V及以下飛機布線、電器、電訊設備和儀器儀表線路。
Suitable for aircraft wiring, electrical, telecommunications equipment, and instrumentation circuits with AC rated voltage of 600V and below in the aviation and electronics industries.
使用特性
Properties
額定電壓600V
Rated voltage 600V
電纜導體的長期允許工人溫度：AF-250、AFP-250為-65℃~250℃。
The long-term allowable worker temperature for cable conductors is -65 ℃~250 ℃ for AF-250 and AFP-250.
AF-200、AFP-200為-40℃~200℃。
AF-200 and AFP-200 range from -40 ℃ to 200 ℃.
型號和名稱
Model and name
型號
model
名稱
name
主要用途
Main purpose
AF-250
AF-250
鍍銀軟圓銅線芯聚四氟乙烯絕緣電線
Silver plated soft round copper wire core PTFE insulated wire
儀表安裝
instrumentation
AFP-250
AFP-250
鍍銀軟圓銅線芯聚四氟乙烯絕緣屏蔽電線
Silver plated soft round copper wire core PTFE insulated shielded wire
AF-200
AF-200
鍍錫軟圓銅線芯氟46絕緣電線
Tin plated soft round copper core fluorine 46 insulated wire
AFP-200
AFP-200
鍍錫軟圓銅線芯氟46絕緣屏蔽電線
Tin plated soft round copper core fluorine 46 insulated shielded wire
電纜規格
Cable specifications
型號
model
芯數
CORE
標稱截面（mm2）
Nominal cross-section (mm2)
AF-250 AFP-250 AF-200 AFP-200
AF-250 AFP-250 AF-200 AFP-200
單芯
core
0.6-6.0
0.6-6.0
注：1.根據雙方協議，允許采用銅線芯。
Note: According to the agreement between both parties, it is allowed to use copper wire cores.
