- 產品名稱：High temperature cable, silicone rubber power flexible cable
- 瀏覽：
- 添加時間：2025-03-25 15:36:02
- 推薦度：
本產品適用于交流額定電壓450/750V及以下移動或固定敷設用電器儀表連接線或信號傳輸，
This product is suitable for connecting wires or signal transmission of mobile or fixed electrical instruments with AC rated voltage of 450/750V and below,
電纜具有較好的熱穩定性，能在高溫、低溫、腐蝕性中保持良好的電性能和柔軟性，適合冶金、電力、石化等行業具有移動耐溫等特殊要求場合使用。
Cables have good thermal stability and can maintain good electrical performance and flexibility in high temperature, low temperature, and corrosive environments. They are suitable for use in industries such as metallurgy, power, and petrochemicals with special requirements for mobile temperature resistance.
控制電纜 硅橡膠計算機電纜 硅橡膠屏蔽信號電纜 硅橡膠高溫鎧裝電纜 硅橡膠扁電纜 硅橡膠高壓電纜 硅橡膠阻燃電纜 硅橡膠電機引接線 硅橡膠補償導線
Control cable, silicone rubber computer cable, silicone rubber shielded signal cable, silicone rubber high-temperature armored cable, silicone rubber flat cable, silicone rubber high-voltage cable, silicone rubber flame retardant cable, silicone rubber motor lead wire, silicone rubber compensation wire
一： 產品特點及用途：本產品適用于交流額定電壓0.6/1KV及以下固定敷設用動力傳輸線或移動電器用連接電纜，產品具有耐熱輻射、耐寒、耐酸堿及腐蝕性氣 體、防水等特性，電纜結構柔軟，輻射方便，高溫（高寒）環境下電氣性能穩定，抗老化性能突出，使用壽命長，廣泛用于冶金、電力、石化、電子、汽車制
1： Product features and uses: This product is suitable for power transmission lines for fixed laying or connecting cables for mobile appliances with AC rated voltage of 0.6/1KV and below. The product has the characteristics of heat radiation resistance, cold resistance, acid alkali resistance, corrosive gas resistance, waterproof, etc. The cable structure is soft, radiation is convenient, and the electrical performance is stable under high temperature (high cold) environment, with outstanding anti-aging performance and long service life. It is widely used in metallurgy, power, petrochemical, electronics, and automobile manufacturing
本產品適用于交流額定電壓450/750V及以下移動或固定敷設用電器儀表連接線或信號傳輸，電纜具有較好的熱穩定性，能在高溫、低溫、腐蝕性中保持良好本產品適用于交流額定電壓450/750V及以下移動或固定敷設用電器儀表連接線或信號傳輸，電纜具有較好的熱穩定性，能在高溫、低溫、腐蝕性中保持良好的電性能和柔軟性，適合冶金、電力、石化等行業具有移動耐溫等特殊要求場合使用。
This product is suitable for mobile or fixed electrical instrument connection lines or signal transmission with AC rated voltage of 450/750V and below. The cable has good thermal stability and can maintain good performance in high temperature, low temperature, and corrosion. This product is suitable for mobile or fixed electrical instrument connection lines or signal transmission with AC rated voltage of 450/750V and below. The cable has good thermal stability and can maintain good electrical performance and flexibility in high temperature, low temperature, and corrosion. It is suitable for use in industries such as metallurgy, power, and petrochemicals with special requirements for mobile temperature resistance.
二：產品執行標準
2： Product execution standards
Q/HHTZH004.2
Q/HHTZH004.2
阻燃耐火特性試驗執行GB12666-90標準
The flame retardant and fire-resistant characteristics test shall comply with GB12666-90 standard
三：使用特性
3： Usage characteristics
1. 交流額定電壓：U/U 450/750KV
1. Rated AC voltage: U/U 450/750KV
最高工作溫度：180℃
Maximum operating temperature: 180 ℃
2. 最低環境溫度：硅橡膠護套：固定敷設-60℃，非固定敷設-20℃
2. Minimum ambient temperature: Silicone rubber sheath: fixed installation -60 ℃, non fixed installation -20 ℃
3. 電纜安裝敷設溫度應不低于-20℃。
3. The temperature for cable installation and laying should not be lower than -20 ℃.
的電性能和柔軟性，適合冶金、電力、石化等行業具有移動耐溫等特殊要求場合使用。
Its electrical performance and flexibility make it suitable for use in industries such as metallurgy, power, and petrochemicals with special requirements for mobility and temperature resistance.
本產品適用于交流額定電壓450/750V及以下移動或固定敷設用電器儀表連接線或信號傳輸，
This product is suitable for connecting wires or signal transmission of mobile or fixed electrical instruments with AC rated voltage of 450/750V and below,
電纜具有較好的熱穩定性，能在高溫、低溫、腐蝕性中保持良好的電性能和柔軟性，適合
Cables have good thermal stability and can maintain good electrical performance and flexibility in high temperature, low temperature, and corrosive environments, making them suitable for
冶金、電力、石化等行業具有移動耐溫等特殊要求場合使用。
Used in industries such as metallurgy, power, and petrochemicals with special requirements for mobile temperature resistance.
使用特性
Properties
1.交流額定電壓：U0/U 450/750KV
1. Rated AC voltage: U0/U 450/750KV
最高工作溫度：180℃
Maximum operating temperature: 180 ℃
2.最低環境溫度：硅橡膠護套：固定敷設-60℃，非固定敷設-20℃
2. Minimum ambient temperature: Silicone rubber sheath: fixed installation -60 ℃, non fixed installation -20 ℃
3.電纜安裝敷設溫度應不低于-20℃。
3. The temperature for cable installation and laying should not be lower than -20 ℃.
4.電纜允許彎曲半徑：非鎧裝電纜最小為電纜外徑的6倍
4. Allowable bending radius for cables: The minimum allowable bending radius for non armored cables is 6 times the outer diameter of the cable
交流額定電壓：U0/U 0.6/1KV
Rated AC voltage: U0/U 0.6/1KV
最高工作溫度： 180℃
Maximum operating temperature: 180℃
最低環境溫度：固定敷設-60℃
Minimum ambient temperature: Fixed installation -60 ℃
2.電纜安裝敷設溫度應不低于-25℃。
2. The temperature for cable installation and laying should not be lower than -25 ℃.
3.電纜允許彎曲半徑：電纜最小為電纜外徑的10倍電纜的型號、名稱和用途、使用特性
3. Allowable bending radius for cables: The minimum allowable bending radius for cables is 10 times the outer diameter of the cable. The model, name, purpose, and usage characteristics of the cable
使用特性
Properties
1.交流額定電壓：U0/U 450/750KV
1. Rated AC voltage: U0/U 450/750KV
最高工作溫度：180℃
Maximum operating temperature: 180 ℃
2.最低環境溫度：硅橡膠護套：固定敷設-60℃，非固定敷設-20℃
2. Minimum ambient temperature: Silicone rubber sheath: fixed installation -60 ℃, non fixed installation -20 ℃
3.電纜安裝敷設溫度應不低于-20℃。
3. The temperature for cable installation and laying should not be lower than -20 ℃.
4.電纜允許彎曲半徑：非鎧裝電纜最小為電纜外徑的6倍
4. Allowable bending radius for cables: The minimum allowable bending radius for non armored cables is 6 times the outer diameter of the cable
