- 產品名稱：Silicone rubber high-voltage cable JGG 10KV
- 瀏覽：
- 添加時間：2025-03-25 16:15:56
- 推薦度：
JGG-10 10KV硅橡膠絕緣硅橡膠護套高壓電纜
JGG-10 10KV Silicone Rubber Insulated Silicone Rubber Sheathed High Voltage Cable
產品特點及用途: 適用于交流額定電壓0.6/1KV及以下固定敷設用動力傳輸線或移動電器用連接電纜，產品具有耐熱輻射、耐寒、耐酸堿及腐蝕性氣體、防水等特性，電纜結構柔軟，輻射方便，高溫（高寒）環境下電氣性能穩定，抗老化性能突出，使用壽命長，廣泛用于冶金、電力、石化、電子、汽車制造等行業。
Product features and uses: applicable to power transmission lines for fixed laying or connecting cables for mobile appliances with AC rated voltage of 0.6/1KV and below. The product has the characteristics of heat radiation resistance, cold resistance, acid alkali resistance, corrosive gas resistance, waterproof, etc. The cable structure is soft, radiation convenient, electrical performance is stable under high temperature (high cold) environment, anti-aging performance is outstanding, and service life is long. It is widely used in metallurgy, power, petrochemical, electronics, automobile manufacturing and other industries.
硅橡膠電機連接線線產品簡介:
Silicone rubber motor connecting wire product introduction:
1．硅橡膠電機連接線交流額定電壓:U0/U 0.6/1KV***高工作溫度: 180℃***低環境溫度:固定敷設-60℃.
1. Silicone rubber motor connecting wire AC rated voltage: U0/U 0.6/1KV Maximum operating temperature: 180 ℃ Minimum ambient temperature: Fixed installation -60 ℃
2．電纜安裝敷設溫度應不低于-25℃。
2. The temperature for cable installation and laying should not be lower than -25 ℃.
3．電纜允許彎曲半徑:電纜***小為電纜外徑的10倍
3. Allowable bending radius for cables: The minimum allowable bending radius for cables is 10 times the outer diameter of the cable
硅橡膠電機引接線
Silicone rubber motor lead wire
型號說明
Model Description
JG
JG
鍍錫銅導體硅橡膠絕緣電機引接線電纜
Tin plated copper conductor silicone rubber insulated motor lead wire cable
JGG-1
JGG-1
1KV鍍錫銅導體硅橡膠絕緣電機引接線電纜
1KV tinned copper conductor silicone rubber insulated motor lead wire cable
JGG-6
JGG-6
6KV硅橡膠絕緣硅橡膠護套高壓電纜
6KV silicone rubber insulated silicone rubber sheathed high-voltage cable
JGG-10
JGG-10
10KV硅橡膠絕緣硅橡膠護套高壓電纜
10KV silicone rubber insulated silicone rubber sheathed high-voltage cable
JGGP
JGGP
硅橡膠絕緣硅橡膠護套銅編織屏蔽電纜
Silicone rubber insulated, silicone rubber sheathed, copper braided shielded cable
