- 產品名稱：BPYJVTP2 frequency conversion cable
- 瀏覽：
- 添加時間：2025-03-27 15:14:57
- 推薦度：
產品簡介
Product Introduction
BPYJVTP2變頻電纜|價格，變頻電纜主要用于變頻電源和變頻電機之間連接用的電纜，以及額定電壓1kV及以下的輸配電線路中，作輸送電能用。尤其適用于造紙、冶金、紡織、金屬加工、礦山、鐵路和食品加工等行業。
BPYJVTP2 Variable Frequency Cable | Price, Variable Frequency Cable is mainly used as a cable for connecting variable frequency power supplies and variable frequency motors, as well as for transmitting electrical energy in transmission and distribution lines with a rated voltage of 1kV or below. Especially suitable for industries such as papermaking, metallurgy, textiles, metal processing, mining, railways, and food processing.
BPYJVTP2變頻電纜|BPYJVTP2變頻電纜價格使用條件
BPYJVTP2 Variable Frequency Cable | Price and Usage Conditions of BPYJVTP2 Variable Frequency Cable
1、額定電壓U0/U：0.6/1kV。
1. Rated voltage U0/U: 0.6/1kV.
2、電纜導體長期允許zui高溫度為90℃，短路時zui高溫度為250℃（zui長持續時間為5秒）。
2. The maximum allowable temperature for cable conductors in the long term is 90 ℃, and the maximum allowable temperature during short circuits is 250 ℃ (with a maximum duration of 5 seconds).
3、安裝敷設環境溫度不低于0℃，固定敷設時環境溫度不低于-10℃。
3. The installation and laying environment temperature shall not be lower than 0 ℃, and the fixed laying environment temperature shall not be lower than -10 ℃.
4、電纜允許zui小彎曲半徑不小于15D（D-電纜外徑，mm）。
4. The maximum allowable bending radius for cables is not less than 15D (D - cable outer diameter, mm）。
|價格產品性能
|Price Product Performance
1、BPYJVP 、BPYJVP2、BPYJVPR、BPYJVP2R、
1 BPYJVP 、BPYJVP2、BPYJVPR、BPYJVP2R、
BPYJVTP2、BPYJVPLPR、BPYJVPLP1R、BPYJVP2PR型
BPYJVTP2, BPYJVPLPR, BPYJVPLP1R, BPYJVP2PR types
設計采用符合GB/T3956規定的銅導體。原型號前加ZR---表示阻燃型
The design adopts copper conductors that comply with GB/T3956 regulations. Add ZR before the prototype number to indicate flame retardant type
2、交聯聚乙烯絕緣，耐溫耐候性好。
2. Cross linked polyethylene insulation has good temperature and weather resistance.
3、低傳輸阻抗，電磁兼容性好。
3. Low transmission impedance, good electromagnetic compatibility.
4、低工作電容。
4. Low working capacitance.
5、良好的抗干擾和低輻射性能。
5. Good anti-interference and low radiation performance.
6、對稱的三芯電纜結構設計，具有比四芯電纜更好的傳輸性能。
6. The symmetrical three core cable structure design has better transmission performance than four core cables.
型號 Type | 名稱 Description | |||||||||||||||
BPYJVP、 | 銅芯交聯聚乙烯絕緣聚氯乙烯護套銅絲編織屏蔽變頻（軟）電纜 | |||||||||||||||
BPYJVPR | Frequency converter (flexible) cable with copper core, XLPE insulation, copper wire braid shielding, PVC sheath | |||||||||||||||
BPYJVP2、 | 銅芯交聯聚乙烯絕緣聚氯乙烯護套銅帶繞包屏蔽變頻（軟）電纜 | |||||||||||||||
BPYJVP2R | Frequency converter (flexible) cable with copper core, XLPE insulation, copper tape wrapped shielding, PVC sheath | |||||||||||||||
銅芯交聯聚乙烯絕緣聚氯乙烯護套銅絲纏繞+銅帶繞包屏蔽變頻電纜 | ||||||||||||||||
BPYJVTP2 | Frequency converter cable with copper core, XLPE insulation, copper wire winding plus copper tape wrapped | |||||||||||||||
shielding, PVC sheath | ||||||||||||||||
銅芯交聯聚乙烯絕緣聚氯乙烯護套鋁箔繞包屏蔽+銅絲編織屏蔽變頻軟電纜 | ||||||||||||||||
BPYJVPLPR | Frequency converter cable with copper core, XLPE insulation, AL. polyester winding plus copper wire braided | |||||||||||||||
shielding, PVC sheath | ||||||||||||||||
銅芯交聯聚乙烯絕緣聚氯乙烯護套鋁箔繞包屏蔽+鍍錫絲編織屏蔽變頻軟電纜 | ||||||||||||||||
BPYJVPLP1R | Frequency converter cable with copper core, XLPE insulation, AL. polyester winding plus copper tape wrapped | |||||||||||||||
shielding, PVC sheath | ||||||||||||||||
銅芯交聯聚乙烯絕緣聚氯乙烯護套銅帶繞包+銅絲編織屏蔽變頻軟電纜 | ||||||||||||||||
BPYJVP2PR | Frequency converter cable with copper core, XLPE insulation, copper wire winding plus tinned copper wire braided | |||||||||||||||
wrapped shielding, PVC sheath | ||||||||||||||||
銅芯交聯聚乙烯絕緣聚氯乙烯護套銅帶繞包+鍍錫絲編織屏蔽變頻軟電纜 | ||||||||||||||||
BPYJVP2PIR | Frequency converter cable with copper core, XLPE insulation, copper tape winding plus tinned copper wire wrapped | |||||||||||||||
shielding, PVC sheath | ||||||||||||||||
.
名 稱 Item | 代 號Code | 說 明 Description |
系列代號 Series No | BP | 變頻電纜frequency converter cable |
絕緣代號 Insulation No. | YJ | 交聯聚乙烯絕緣XLPE insulation |
護套代號Sheath Code | V | 聚氯乙烯護套PVC sheath |
WD | 無鹵低煙聚烯烴護套 LSZH sheath | |
銅絲纏繞+銅帶繞包屏蔽 | ||
TP2 | Copper wire twine--copper tape wrapped shielding | |
銅帶繞包+銅絲編織屏蔽 | ||
屏蔽代號 Shielding Code | P2P | |
Copper tape wrapped--copper wire braided shielding | ||
PLP1 | ||
鋁帶繞包+鍍錫銅絲編織屏蔽 | ||
Al. Polyester tape wrapped--tinned copper wire braid shielding | ||
鋼帶鎧裝聚氯乙烯護套 | ||
鎧裝代號 Armour Code | 22 | Steel tape Armour, PVC sheath |
23 | 鋼帶鎧裝聚烯烴護套鋼帶鎧裝聚乙烯護套 | |
Steel tape Armour, polyolefin sheath; steel tape armored, PE sheath | ||
阻燃代號Flame retardant Code | ZR | 阻燃型（C類） |
flame-retardant type (category C) | ||
