- 產品名稱：High temperature variable frequency cable BPGGRP
- 瀏覽：
- 添加時間：2025-04-07 16:18:35
- 推薦度：
產品特點及用途 本產品適用于交流U0/U為300/500V電力、冶金、石化等行業以電子計算機為主的自動控制系統、計算機集散控制系統、自動化控制系統作控制線以及檢測用儀器儀表用電子計算機電纜。
Product features and uses: This product is suitable for automatic control systems, computer distributed control systems, control lines for automation control systems, and electronic computer cables for testing instruments and meters in industries such as AC U0/U 300/500V power, metallurgy, petrochemicals, etc., mainly using electronic computers.
二：產品執行標準
2： Product execution standards
Q/HL002-2002(等效采用英國BS5308標準)
Q/HL002-2002 (Equivalent to British BS5308 standard)
阻燃性能試驗執行GB12666-90標準
Flame retardant performance test shall comply with GB12666-90 standard
三：使用特性
3： Usage characteristics
1． 交流額定電壓：U0/U 300/500KV
1. Rated AC voltage: U0/U 300/500KV
2． 工作溫度：聚乙烯絕緣不超過70℃
2. Working temperature: Polyethylene insulation not exceeding 70 ℃
交聯聚乙烯絕緣90℃
Cross linked polyethylene insulation at 90 ℃
低煙無鹵阻燃聚烯烴70℃
Low smoke halogen-free flame-retardant polyolefin at 70 ℃
低煙無鹵阻燃交聯聚烯烴90℃和125℃兩種
Low smoke halogen-free flame-retardant cross-linked polyolefin at 90 ℃ and 125 ℃
3． ***環境溫度：聚氯乙烯護套：固定敷設-40℃，非固定敷設-15℃
3. * * * Environmental temperature: PVC sheath: fixed installation -40 ℃, non fixed installation -15 ℃
4． 電纜安裝敷設溫度應不低于0℃。
4. The temperature for cable installation and laying should not be lower than 0 ℃.
5． 電纜允許彎曲半徑：非鎧裝電纜最小為電纜外徑的6倍
5. Allowable bending radius for cables: The minimum allowable bending radius for non armored cables is 6 times the outer diameter of the cable
銅帶屏蔽或鋼帶鎧裝電纜最小為電纜外徑的12倍
The minimum requirement for copper tape shielded or steel tape armored cables is 12 times the outer diameter of the cable
6、用途：使用于抗干擾性能要求較高的電纜，也可以使用于抗干擾性能較高的檢測儀器、儀表連接線用的電纜
6. Purpose: Used for cables with high anti-interference performance requirements, as well as cables for testing instruments and instrument connection lines with high anti-interference performance
