- 產品名稱：ZR-BPYJVPX13R Variable Frequency Cable
- 瀏覽：
- 添加時間：2025-04-10 14:09:38
- 推薦度：
產品介紹
Product Introduction
ZR-BPYJVPX13R-1KV變頻電纜產品特點
ZR-BPYJVPX13R-1KV Variable Frequency Cable Product Features
1、較低的有效電容；
1. Lower effective capacitance;
2、具有屏蔽性能，高密度編織屏蔽及復合屏蔽設計使電纜具有良好的抗電磁干擾、電磁輻射的性能，有利于新型短路自動保護設備的應用。
2. With shielding performance, high-density braided shielding and composite shielding design make the cable have good resistance to electromagnetic interference and radiation, which is conducive to the application of new short-circuit automatic protection equipment.
4、較低且均勻的正（逆）序和零序阻抗，與普通四芯電纜相比*改善了供電品質：該電纜含有屏蔽層，以防止電磁干擾，傳輸阻抗RX是對屏蔽抗感應和電容耦合的有效性的量度，低傳輸阻抗可提供良好的電磁相容性。
4. The lower and uniform positive (reverse) and zero sequence impedances improve the power supply quality compared to ordinary four core cables: the cable contains a shielding layer to prevent electromagnetic interference, and the transmission impedance RX is a measure of the effectiveness of shielding against induction and capacitive coupling. Low transmission impedance can provide good electromagnetic compatibility.
5、*對稱的三芯設計，更好的電磁兼容性，比四芯電纜更好的性能。三根耐侯耐溫樹脂絕緣線芯在縫隙處勻等距絞合，形成一種真正的同心結構。
5. Symmetrical three core design, better electromagnetic compatibility, and better performance than four core cables. Three weather resistant and temperature resistant resin insulated wire cores are evenly and equally twisted at the gap to form a true concentric structure.
6、*屏蔽了高次諧波電流分量對其他控制電路的干擾。
6. Shielded the interference of high-order harmonic current components on other control circuits.
7、屏蔽層的截面設計與主線芯達到一定比例，可用作PE接地線芯。
7. The cross-sectional design of the shielding layer is proportional to the main wire core and can be used as a PE grounding wire core.
8、電纜導體的zui高工作溫度與絕緣材料相適應。
8. The maximum working temperature of cable conductors is compatible with the insulation material.
9、采用低煙無鹵阻燃護層，電纜在發生火災時具有發煙少，無有體等優點，使用更安全更環保，也可以制造成耐火燃燒型，可用于危險區域；
9. Adopting a low smoke halogen-free flame retardant protective layer, the cable has the advantages of low smoke emission and no body in case of fire, making it safer and more environmentally friendly to use. It can also be manufactured into a fire-resistant combustion type and can be used in hazardous areas;
10、試驗電壓：3.5kV/5min ；脈沖雷擊電壓：正負10次，40kV不擊穿。
10. Test voltage: 3.5kV/5min; Pulse lightning voltage: positive or negative 10 times, 40kV without breakdown.
ZR-BPYJVPX13R-1KV變頻電纜應用范圍
Application scope of ZR-BPYJVPX13R-1KV variable frequency cable
由變頻器用供電電纜和頻率控制電機組成了的傳動統。它用于頻率控制傳動系統中作供電電纜或連接電纜。該系統的電纜尤其適用于鋼鐵、石油化工、電廠、造紙、紡織、金屬加工和食品加工的自動化生產線的輸送機、傳輸線以及各類壓力泵、鼓風機、集中空調等。
A transmission system composed of power cables for frequency converters and frequency controlled motors. It is used as a power cable or connecting cable in frequency control transmission systems. The cables of this system are particularly suitable for conveyors, transmission lines, as well as various pressure pumps, blowers, central air conditioners, etc. in automated production lines for steel, petrochemicals, power plants, papermaking, textiles, metal processing, and food processing.
允許溫度及工作電壓
Allowable temperature and operating voltage
1、交聯聚乙烯絕緣變頻電纜允許導體連續工作zui高溫度90℃，短路時zui高溫度250℃。
1. Cross linked polyethylene insulated variable frequency cables allow conductors to operate continuously at a maximum temperature of 90 ℃, and during short circuits at a maximum temperature of 250 ℃.
硅橡膠絕緣變頻電纜允許導體連續工作zui高溫度150℃，短路時zui高溫度250℃。
The silicone rubber insulated variable frequency cable allows the conductor to operate continuously at a maximum temperature of 150 ℃ and a maximum temperature of 250 ℃ during a short circuit.
2、交聯型變頻電纜在運輸、儲存、輻射、搬運和作業時自由彎曲≥+5℃，固定敷設：≥0℃。
2. Cross linked variable frequency cables can be freely bent at ≥+5 ℃ during transportation, storage, radiation, handling, and operation. Fixed laying: ≥ 0 ℃.
硅橡膠絕緣變頻電纜在運輸、儲存、輻射、搬運和作業時自由彎曲≥-20℃，固定敷設：≥-25℃。
Silicone rubber insulated variable frequency cables can be freely bent at ≥ -20 ℃ during transportation, storage, radiation, handling, and operation, and can be fixedly laid at ≥- 25 ℃.
3、電纜彎曲半徑為電纜直徑的12倍，軟電纜為電纜直徑的6倍。
3. The bending radius of the cable is 12 times the diameter of the cable, and the bending radius of the flexible cable is 6 times the diameter of the cable.
4、額定電壓為600/1000V，交流試驗電壓3500V。
4. The rated voltage is 600/1000V, and the AC test voltage is 3500V.
BPYJVTP2-0.6/1KV | 銅芯交聯聚乙烯絕緣聚氯乙烯護套銅絲纏繞+銅帶繞包屏蔽0.6/1KV變頻電纜 Copper core cross-linked polyethylene insulated polyvinyl chloride sheathed copper wire winding+copper tape winding shielding 0.6/1KV variable frequency cable |
ZR-BPYJVTP2-0.6/1KV | 銅芯交聯聚乙烯絕緣阻燃聚氯乙烯護套銅絲纏繞+銅帶繞包屏蔽阻燃型0.6/1KV變頻電纜 Copper core cross-linked polyethylene insulated flame-retardant polyvinyl chloride sheathed copper wire winding+copper tape winding shielded flame-retardant 0.6/1KV variable frequency cable |
BPYJVP12R-0.6/1KV | 銅芯交聯聚乙烯絕緣聚氯乙烯護套銅帶繞包+銅絲編織雙屏蔽0.6/1KV變頻軟電纜 Copper core cross-linked polyethylene insulated polyvinyl chloride sheathed copper tape winding+copper wire braided double shielded 0.6/1KV variable frequency flexible cable |
ZR-BPYJVP12 R-0.6/1KV | 銅芯交聯聚乙烯絕緣阻燃聚氯乙烯護套銅帶繞包+銅絲編織雙屏蔽阻燃型0.6/1KV變頻軟電纜 Copper core cross-linked polyethylene insulated flame-retardant polyvinyl chloride sheathed copper tape winding+copper wire braided double shielded flame-retardant 0.6/1KV variable frequency flexible cable |
BPYJVPX13R-0.6/1KV | 銅芯交聯聚乙烯絕緣聚氯乙烯護套鋁帶繞包+鍍錫銅絲編織雙屏蔽0.6/1KV變頻軟電纜 Copper core cross-linked polyethylene insulated PVC sheathed aluminum tape winding+tinned copper wire braided double shielded 0.6/1KV variable frequency flexible cable |
ZR-BPYJVPX13R-0.6/1KV | 銅芯交聯聚乙烯絕緣阻燃聚氯乙烯護套鋁帶繞包+鍍錫銅絲編織雙屏蔽阻燃型0.6/1KV變頻軟電纜 Copper core cross-linked polyethylene insulated flame-retardant polyvinyl chloride sheathed aluminum tape winding+tinned copper wire braided double shielded flame-retardant 0.6/1KV variable frequency flexible cable |
BPYJVTP2-1.8/3KV | 銅芯交聯聚乙烯絕緣聚氯乙烯護套銅絲纏繞+銅帶繞包屏蔽1.8/3KV變頻電纜 Copper core cross-linked polyethylene insulated polyvinyl chloride sheathed 1.8/3KV variable frequency cable with copper wire winding and copper tape wrapping shielding |
ZR-BPYJVTP2-1.8/3KV | 銅芯交聯聚乙烯絕緣阻燃聚氯乙烯護套銅絲纏繞+銅帶繞包屏蔽阻燃型1.8/3KV變頻電纜 Copper core cross-linked polyethylene insulated flame-retardant polyvinyl chloride sheathed copper wire winding+copper tape winding shielded flame-retardant 1.8/3KV variable frequency cable |
BPYJVP12R-1.8/3KV | 銅芯交聯聚乙烯絕緣聚氯乙烯護套銅帶繞包+銅絲編織雙屏蔽1.8/3KV變頻軟電纜 Copper core cross-linked polyethylene insulated polyvinyl chloride sheathed copper tape winding+copper wire braided double shielded 1.8/3KV variable frequency flexible cable |
ZR-BPYJVP12R-1.8/3KV | 銅芯交聯聚乙烯絕緣阻燃聚氯乙烯護套銅帶繞包+銅絲編織雙屏蔽阻燃型1.8/3KV變頻軟電纜 Copper core cross-linked polyethylene insulated flame-retardant polyvinyl chloride sheathed copper tape winding+copper wire braided double shielded flame-retardant 1.8/3KV variable frequency flexible cable |
BPYJVPX13R-1.8/3KV | 銅芯交聯聚乙烯絕緣聚氯乙烯護套鋁帶繞包+鍍錫銅絲編織雙屏蔽1.8/3KV變頻軟電纜 Copper core cross-linked polyethylene insulated polyvinyl chloride sheathed aluminum tape winding+tinned copper wire braided double shielded 1.8/3KV variable frequency flexible cable |
ZR-BPYJVPX13R-1.8/3KV | 銅芯交聯聚乙烯絕緣阻燃聚氯乙烯護套鋁帶繞包+鍍錫銅絲編織雙屏蔽阻燃型1.8/3KV變頻軟電纜 Copper core cross-linked polyethylene insulated flame-retardant polyvinyl chloride sheathed aluminum tape winding+tinned copper wire braided double shielded flame-retardant 1.8/3KV variable frequency flexible cable |
