- 產品名稱：Steel tape armored high-temperature cable KHF46F22
- 瀏覽：
- 添加時間：2025-05-07 14:43:42
- 推薦度：
高溫氟塑料絕緣氟塑料護套電纜
High temperature fluoroplastic insulated fluoroplastic sheathed cable
1、氟塑料護套；2隔離帶；3、金屬屏蔽；4、聚脂或F4帶繞包；
1. Fluoroplastic sheath; 2 isolation zones; 3. Metal shielding; 4. Polyester or F4 tape wrapping;
5、FEP絕緣；6、導體；
5. FEP insulation; 6. Conductor;
KHF46FR高溫氟塑護套電纜阻燃控制電纜
KHF46FR high-temperature fluoroplastic sheathed cable flame retardant control cable
型號名稱及規格：
Model name and specifications:
型號 名稱 規格
Model Name Specification
芯數 標稱截面
Number of cores, nominal cross-section
KHF46FR 鍍錫銅芯氟塑料絕緣氟塑料護套控制軟電纜 (2—37芯 )(1.5、2.5 4、6、10 )
KHF46FR Tin plated Copper Core Fluoroplastic Insulation Fluoroplastic Sheath Control Flexible Cable (2-37 cores) (1.5, 2.5, 4, 6, 10)
KHF46FRP 鍍錫銅芯氟塑料絕緣氟塑料護套編織屏蔽控制軟電纜 (2—37芯)( 1.5、2.5 4、6、10 )
KHF46FRP Tin Plated Copper Core Fluoroplastic Insulated Fluoroplastic Sheath Braided Shielded Control Flexible Cable (2-37 cores) (1.5, 2.5, 4, 6, 10)
KHF46FRP2 鍍錫銅芯氟塑料絕緣氟塑料護套銅帶屏蔽控制軟電纜 (2—37芯)( 1.5、2.5 4、6、10 )
KHF46FRP2 Tin plated Copper Core Fluoroplastic Insulated Fluoroplastic Sheath Copper Tape Shielded Control Flexible Cable (2-37 cores) (1.5, 2.5, 4, 6, 10)
KHF46F 鍍錫銅芯氟塑料絕緣氟塑料護套控制電纜 ( 2—37芯 )(1.5、2.5 4、6、10 )
KHF46F Tin plated Copper Core Fluoroplastic Insulated Fluoroplastic Sheathed Control Cable (2-37 cores) (1.5, 2.5, 4, 6, 10)
KHF46FP 鍍錫銅芯氟塑料絕緣氟塑料套編織屏蔽控制電纜 (2—37芯)( 1.5、2.5 4、6、10 )
KHF46FP Tin Plated Copper Core Fluoroplastic Insulated Fluoroplastic Sleeve Braided Shielded Control Cable (2-37 cores) (1.5, 2.5, 4, 6, 10)
KHF46FP2 鍍錫銅芯氟塑料絕緣氟塑料護套銅帶屏蔽控制電纜 ( 2—37芯)( 1.5、2.5 4、6、10 )
KHF46FP2 Tin Plated Copper Core Fluoroplastic Insulated Fluoroplastic Sheath Copper Tape Shielded Control Cable (2-37 cores) (1.5, 2.5, 4, 6, 10)
KHF46F22 鍍錫銅芯氟塑料絕緣氟塑料護套鋼帶鎧裝控制電纜( 2—37芯)( 1.5、2.5 4、6、10 )
KHF46F22 Tin plated Copper Core Fluoroplastic Insulated Fluoroplastic Sheath Steel Strip Armored Control Cable (2-37 cores) (1.5, 2.5, 4, 6, 10)
KHF46F32 鍍錫銅芯氟塑料絕緣氟塑料護套細銅絲鎧裝控制電纜(2—37 芯)(1.5、2.5 4、6、10 )
KHF46F32 Tin plated Copper Core Fluoroplastic Insulated Fluoroplastic Sheath Thin Copper Wire Armored Control Cable (2-37 cores) (1.5, 2.5, 4, 6, 10)
