耐高溫控制電纜產品特點:
Characteristics of high temperature resistant control cable products:
1、產品用途：耐高溫控制電纜 適用于交直流額定電壓450/750V及以下的高溫，有腐蝕性氣體等環境較惡劣的范圍內的信號的傳輸及控制線路。
1. Product use: High temperature resistant control cable is suitable for signal transmission and control circuits in environments with high temperature, corrosive gases, and other harsh conditions, such as AC/DC rated voltage of 450/750V and below.
2、產品使用特性
2. Product usage characteristics
電纜有耐高溫、耐堿、耐油、耐氧化劑等特性。電纜線芯長期允許工作溫度為-40℃－－+200℃。電纜彎曲半徑不小于電纜外徑的6倍。電纜使用最低溫度為-55℃。
Cables have characteristics such as high temperature resistance, alkali resistance, oil resistance, and oxidation resistance. The long-term allowable working temperature for cable cores is -40 ℃ -+200 ℃. The bending radius of the cable shall not be less than 6 times the outer diameter of the cable. The minimum temperature for cable usage is -55 ℃.
3、電纜的型號、名稱及使用范圍
3. Cable model, name, and scope of use
型號 名稱 使用范圍 15933646514 5198680
Model Name Usage Range 15933646514 5198680
KHF46 氟塑料絕緣、 聚氯乙烯護套耐高溫控制電纜 固定敷設在室內、電纜溝或管道中
KHF46 fluoroplastic insulated and polyvinyl chloride sheathed high temperature resistant control cable is fixed and laid indoors, in cable trenches or pipelines
KHF46R 氟塑料絕緣、 聚氯乙烯護套耐高溫軟控制電纜 適用于要求柔軟的場合
KHF46R fluoroplastic insulated and polyvinyl chloride sheathed high-temperature resistant soft control cable is suitable for applications that require flexibility
KHF46P 氟塑料絕緣、 聚氯乙烯護套耐高溫屏蔽控制電纜 適用于要求抗干擾場合
KHF46P fluoroplastic insulated and polyvinyl chloride sheathed high-temperature shielded control cable is suitable for applications requiring anti-interference
KHF46RP 氟塑料絕緣、 聚氯乙烯
KHF46RP fluoroplastic insulation, polyvinyl chloride
