- 產品名稱：硅橡膠軟電纜RGGP
- 瀏覽：
- 添加時間：2025-05-29 09:04:56
- 推薦度：
硅橡膠控制電纜適用于航空、航天、鋼鐵、電廠、冶金機械、石油化工等高溫工業中，額定電壓450V/750及以下的控制及臨控回路中。它具有優良的耐高溫、阻燃、耐輻射、耐老化、耐臭氧、耐油、防水等特性，同時具有良好的耐寒性、耐候性。
Silicone rubber control cables are suitable for control and temporary control circuits with a rated voltage of 450V/750 and below in high-temperature industries such as aviation, aerospace, steel, power plants, metallurgical machinery, and petrochemicals. It has excellent characteristics such as high temperature resistance, flame retardancy, radiation resistance, aging resistance, ozone resistance, oil resistance, and waterproofing, as well as good cold resistance and weather resistance.
硅橡膠控制電纜型號、名稱及規格
Model, name and specification of silicone rubber control cable
型號
model
名稱
name
規格
specifications
芯數
Number of cores
截面
section
KGG
KGG
銅芯硅橡膠絕緣硅橡膠護套控制電纜
Copper core silicone rubber insulated silicone rubber sheathed control cable
1～37
1~37
0.5、0.75、1、1.5、2.5、4、6、10
0.5, 0.75, 1, 1.5, 2.5, 4, 6, 10
KGGP
KGGP
銅芯硅橡膠絕緣硅橡膠護套銅絲編織屏蔽控制電纜
Copper core silicone rubber insulated silicone rubber sheathed copper wire braided shielded control cable
1～37
1~37
0.5、0.75、1、1.5、2.5、4、6、10
0.5, 0.75, 1, 1.5, 2.5, 4, 6, 10
RGGP
RGGP
銅芯硅橡膠絕緣硅橡膠護套銅絲編織屏蔽軟電纜
Copper core silicone rubber insulated silicone rubber sheathed copper wire braided shielded flexible cable
1～37
1~37
0.5、0.75、1、1.5、2.5、4、6、10
0.5, 0.75, 1, 1.5, 2.5, 4, 6, 10
KF46GR
KF46GR
銅芯氟塑料絕緣硅橡膠護套控制軟電纜
Copper core fluoroplastic insulated silicone rubber sheathed control flexible cable
1～37
1~37
0.5、0.75、1、1.5、2.5、4、6、10
0.5, 0.75, 1, 1.5, 2.5, 4, 6, 10
KF46GRP
KF46GRP
銅芯氟塑料絕緣硅橡膠護套銅絲編織屏蔽控制軟電纜
Copper core fluoroplastic insulated silicone rubber sheathed copper wire braided shielded control flexible cable
1～37
1~37
0.5、0.75、1、1.5、2.5、4、6、10
0.5, 0.75, 1, 1.5, 2.5, 4, 6, 10
注：RGGP、YGC-KF46R、YGC-KF46RP型與KGGP、KGG型的區別是：RGGP、YGC-KF46R、YGC-KF46R型導體結構是5類或6類軟導體；KGGP、KGG型導體結構是2類導體或7根絞合結構。
Note: The difference between RGGP, YGC-KF46R, YGC-KF46RP type and KGGP, KGG type is that the RGGP, YGC-KF46R, and YGC-KF46R type conductor structures are Class 5 or Class 6 soft conductors; KGGP and KGG type conductor structures are Class 2 conductors or 7 twisted structures.
